| Hardware Version |
| • A1 |
| Number of Ports |
| • 8 10/100/1000Base-T ports |
| • 2 SFP ports |
| Alarm Relay |
| • 1 A at 24 V |
| Diagnostic LEDs |
| • PWR |
| • SFP |
| • Link/Activity |
| Port Functions |
| • IEEE 802.3 for Ethernet |
| • IEEE 802.3u for Fast Ethernet |
| • IEEE 802.3ab for Gigabit Ethernet |
| • IEEE 802.3z for Gigabit fiber |
| • IEEE 802.3x Flow Control |
| • IEEE 802.3az Energy-Efficient Ethernet (EEE) |
| Media Interface Exchange |
| • Auto-MDI/MDIX adjustment for all twisted pair ports |
| Switching Capacity |
| • 20 Gbps |
| Transmission Method |
| • Store-and-forward |
| Maximum Forwarding Rate |
| • 14.88 Mpps |
| MAC Address Table Size |
| • Up to 4K entries |
| Jumbo Frame |
| • 9.6 KB |
| Advanced Features |
| • IEEE 802.1p Quality of Service (QoS) - 8 hardware queues per port |
| Physical Parameters |
| Power Input |
| • 12 to 48 V DC terminal block dual input |
| Power Consumption |
| • Maximum: 8.44 W |
| • Standby: 2.64 W |
| Heat Dissipation |
| • 25.37 BTU/hr |
| MTBF |
| • 392,267 hrs |
| Weight |
| • 0.4977 kg |
| Dimensions |
| • 100 x 28 x 190 mm |
| Ventilation |
| • Fanless, passive cooling |
| Temperature |
| • Operating: -20° to 65°C |
| • Storage: -40° to 85°C |
| Humidity |
| • Operating: 5% to 95% non-condensing |
| • Storage: 5% to 95% non-condensing |
| Material |
| • IP40-rated metal casing |
| Installation |
| • DIN rail |
| Certifications |
| • CE |
| • FCC |
| EMI |
| • 47 CFR FCC Part 15 Subpart B (Class A) |
| • ICES-003 Issue 6 (Class A) |
| EMS |
| • EN 61000-4-2 ESD |
| • EN 61000-4-3 RS |
| • EN 61000-4-4 EFT |
| • EN 61000-4-5 Surge |
| • EN 61000-4-6 CS |
| • EN 61000-4-8 |
| Environmental Tests |
| • IEC 60068-2-27 Shock |
| • IEC 60068-2-32 Freefall |
| • IEC 60068-2-6 Vibration |
