| Hardware Version |
| • A1 |
| Number of Ports |
| • 8 10/100Base-TX ports |
| Alarm Relay |
| • 1 A at 48 V |
| Diagnostic LEDs |
| • ALM |
| • P1/P2 |
| • Link/Activity/Speed |
| Port Functions |
| • IEEE 802.3 for Ethernet |
| • IEEE 802.3u for Fast Ethernet |
| • IEEE 802.3x Flow Control |
| • IEEE 802.3az Energy-Efficient Ethernet (EEE) |
| Media Interface Exchange |
| • Auto-MDI/MDIX adjustment for all twisted pair ports |
| Switching Capacity |
| • 1.6 Gbps |
| Transmission Method |
| • Store-and-forward |
| Maximum Forwarding Rate |
| • 1.19 Mpps |
| MAC Address Table Size |
| • Up to 1K entries |
| Advanced Features |
| • Broadcast/Multicast/Unicast Storm Control |
| • IEEE 802.1p Quality of Service (QoS) - 2 hardware queues per port |
| Physical Parameters |
| Power Input |
| • 12 to 58 V DC terminal block dual input |
| Power Consumption |
| • Maximum: 1.64 W |
| • Minimum: 1.41 W |
| Heat Dissipation |
| • 5.596 BTU/hr |
| MTBF |
| • > 25 years |
| Weight |
| • 0.405 kg |
| Dimensions |
| • 96.9 x 39 x 117.8 mm |
| Ventilation |
| • Fanless |
| Temperature |
| • Operating: -40° to 75°C |
| • Storage: -40° to 85°C |
| Humidity |
| • Operating: 5% to 95% non-condensing |
| • Storage: 5% to 95% non-condensing |
| Material |
| • IP30-rated metal casing |
| Installation |
| • DIN rail/wall mountable |
| Certifications |
| • UL/CE/FCC |
| Safety |
| • UL60950-1 |
| EMI |
| • 47 CFR FCC Part 15 Subpart B (Class A) |
| • ICES-003 Issue 6 (Class A) |
| EMC |
| • EN61000-6-2 |
| • EN61000-6-4 |
| EMS |
| • EN 61000-4-2 ESD Level 3 |
| • EN 61000-4-3 RS Level 3 |
| • EN 61000-4-4 EFT Level 3 |
| • EN 61000-4-5 Surge Level 3 |
| • EN 61000-4-6 CS Level 3 |
| • EN 61000-4-8 |
| Environmental Tests |
| • IEC 60068-2-27 Shock |
| • IEC 60068-2-32 Freefall |
| • IEC 60068-2-6 Vibration |
