| Video Video Output |
4-ch, DVI-I |
| Video Input |
1-ch, DVI-D and 1-ch, VGA |
| Video Output Resolution |
1024 x 768/ 60HZ, 1280 x 720/ 60HZ, 1280 x 1024/ 60HZ, 1360 x 768/ 60HZ, 1600 x 1200/ 60HZ, 1920 x 1080p/ 60HZ, 1920 x 1080p/ 50HZ |
| Video Compression |
H.264 |
| Video Decoding Resolution |
3MP, 1080p, 1080I, 960p, 720p, 960H, D1, 4CIF, 2CIF, CIF, QCIF |
| Decoding Capability |
4x300W @ 30, 4x1080P @ 60, 8x1080P @ 30,16x720P @ 30,36xD1,64xCIF |
| Display Split |
1/ 3/ 4/ 7/ 9/ 16 |
| Video Wall |
1 x 2, 2 x 1, 2 x 2 |
| Audio Input |
1-ch |
| Output |
4-ch |
| Audio Compression |
G.711μ, G.711a |
| Sound track |
Mono |
| Mute |
Support |
| External Interface Network Interface |
2 RJ-45 10M/100M/1000M adaptive Ethernet Interfaces |
| Serial Interface |
1 x RS-232, 2 x RS-485 |
| Alarm Input |
8-ch |
| Alarm Output |
6-ch |
| General Power Supply |
100~240 VAC |
| Consumption |
50 W |
| Working Temperature |
| Working Humidity |
10% ~ 90% |
| Weight |
≤ 4.0 Kg ( 8.82 lb ) |
| Dimensions ( H x D x W ) |
44 × 320 × 440mm ( 1.7" × 12.6" × 17.3" ) |
