| Camera |
| Sensor |
1/3", 4.0 megapixel, progressive scan, CMOS |
| Lens |
6.0mm@F1.8 |
| Angle of View(H) |
49.4° |
| Shutter |
Auto/Manual, 1/6~1/100000 s |
| Min. Illumination |
Colour: 0.02 Lux (F1.8, AGC ON) |
| 0 Lux with IR on |
| IR Range |
Up to 30m (98 ft) IR range |
| Day/Night |
IR-cut filter with auto switch (ICR) |
| S/N |
>55dB |
| WDR |
120dB |
| Noise Reduction |
2D/3D |
| Video |
| Max. Resolution |
2592×1520 |
| Video Compression |
H.265/H.264/MJPEG |
| Frame Rate |
4MP (2592×1520): Max. 20 fps; 4MP (2560×1440): Max. 25 fps |
| 3MP (2048×1520): Max. 30 fps; 1080P (1920×1080): Max. 30 fps |
| Video Streaming |
Triple |
| 9:16 Corridor Mode |
Supported |
| ROI |
Supported |
| HLC |
Supported |
| Evaluative Metering |
Supported |
| OSD |
Up to 8 OSDs |
| Motion Detection |
Up to 2 areas |
| Privacy Mask |
Up to 4 areas |
| Smart |
| Behavior Detection |
Intrusion, crossing line, motion detection |
| Intelligent Identification |
Face detection, Defocus, Scene Change |
| Statistical Analysis |
People counting |
| Network |
| Protocols |
L2TP, IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x |
| Compatible Integration |
ONVIF, API |
| Interface |
| Network |
1 RJ45 10M/100M Base-TX Ethernet |
| General |
|
| Power |
12 V DC, or PoE (IEEE802.3 af) |
| Power consumption: Max 6.4 W |
| Dimensions (L × W × H) |
157.3 × 62.4 ×63 mm (6.2” × 2.5” × 2.5”) |
| Weight |
0.45 kg (0.99 lb) |
| Working Environment |
-35°C ~ +60°C (-31°F ~ 140°F), Humidity ≤ 95% RH(non-condensing) |
| Ingress Protection |
IP67 |
