| Camera |
| Image Sensor | 1/2.8" Progressive Scan CMOS |
| Min. Illumination | 0.01 Lux @(F1.2,AGC ON), 0 Lux with IR |
| Shutter time | 1/3 s to 1/100,000 s |
| Slow shutter | Support |
| Lens | 4 mm, horizontal field of view: 83° (6 mm: 55°optional) |
| Lens Mount | M12 |
| Day& Night | IR cut filter with auto switch |
| Wide Dynamic Range | Digital WDR |
| Digital noise reduction | 3D DNR |
| Compression Standard |
| Video Compression | H.264/MJPEG |
| H.264 code profile | Baseline profile/Main profile |
| Video bit rate | 32Kbps~8Mbps |
| Dual Stream | Yes |
| Image |
| Max. Image Resolution | 1920 x 1080 |
| Frame Rate | 50Hz: 25fps @( 1920 × 1080, 1280 × 960, 1280 × 720) |
| 60Hz: 30fps @(1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub Stream: | 50Hz: 25fps @(704 × 576, 640 × 480, 352 × 288, 320 × 240) |
| 60Hz: 30fps @(704 × 480, 640 × 480, 352 × 240, 320 × 240) |
| Image Settings | Brightness, saturation, contrast, sharpness are adjustable via web browser or client software |
| BLC | Support |
| Day/Night Switch | Support auto, scheduled |
| Network |
| Alarm Trigger | Motion detection, tampering alarm, network disconnect , IP address conflict |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| General Function | Anti-Flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering |
| Interface |
| Communication Interface | 1 RJ45 10M/100M self-adaptive Ethernet port |
| General |
| Operating Conditions | -30 °C ~ 60 °C (-22 °F ~ 140 °F) |
| Humidity 95% or less (non-condensing) |
| Power Supply | 12 VDC ± 25%, PoE (802.3af Class3) |
| Power Consumption | 12 VDC, 0.38 A, Max. 4.5 W |
| PoE (802.3af, 37 V to 57 V), 0.1 A to 0.16 A, Max. 6 W |
| Weather Proof | IP67 |
| IR Range | Up to 30m |
| Dimensions | 147.5 mm × 78.2 mm × 92.9 mm (5.8" × 3.1" × 3.7") |
| Weight | Approx. 350g (0.8 lb) |
