| SKU |
IBE329-1I |
| Manufacturer |
Pelco |
| Features |
Auto Gain Control, Automatic White Balance, Day/Night, Digital Noise Reduction, Mirror, On Screen Display Menu, ONVIF, Vandal Resistant, Wide Dynamic Range |
| Camera Signal |
Network IP |
| Connection Type |
Wired |
| Infrared Distance |
61~100 Feet |
| Resolution |
3 Megapixel |
| Lens Type |
Varifocal |
| Lens Size |
3-9mm |
| Mount Type |
Ceiling, Wall |
| Compression Method |
H.264, M-JPEG |
| Durability |
Indoor, Vandal Resistant |
| Voltage |
12vDC, 24vAC, PoE |
| Dimensions (W x H) |
13.3 x 6.7 x 6.5 in |
| Electronic Shutter |
1/20,000 sec (or faster) to 2 sec |
| Image Device |
1/2.8-inch Progressive scan CMOS |
| IR LEDs |
850nm |
| Minimum Scene Illumination |
Color (33 ms) 0.050 lux, Color (500 ms) 0.005 lux, Mono (33 ms) 0.010 lux, Mono (500 ms) 0.001 lux, Mono (IR on) 0.000 lux |
| Operating Humidity |
10 to 90%, RH noncondensing |
| Operating Temperature |
–10° to 55°C (14° to 131°F)† |
| OSD Menu |
Arabic, English, French, Italian, German, Korean, Spanish, Portuguese, Russian, Simplified Chinese, Turkish |
| Power Consumption |
8.5 W nominal |
| Protocols |
TCP/IP, UDP/IP (Unicast, Multicast IGMP), UPnP, DNS, DHCP, RTP, RTSP, NTP, IPv4, IPv6, SNMP v2c/v3, QoS, HTTP, HTTPS, SSH, SSL, SMTP, FTP, ARP, ICMP, and 802.1x (EAP), NTCIP 1205 |
| S/N Ratio |
>60 dB |
| Digital Noise Reduction |
3D |
| Mirror |
180°, 90° and 270° (H.264 only) |
| Processor |
Intel® Core™ i3 processor, 2.4 GHz |
| Rotation Angle |
360° |
| Automatic White Balance |
2,000° to 10,000°K |
| IR Distance |
30m/100ft |
| Audio |
Yes |
| Auto Gain Control |
Yes |
| Day/Night |
Yes |
| Digital Noise Reduction |
Yes |
| Automatic White Balance |
Yes |
| Wide Dynamic Range |
Yes |
| ONVIF |
Yes |
