| VIDEO |
| Imaging Device |
1/2.8" 2M CMOS |
| Total Pixels |
1,945(H) x 1,109(V) 2.16M |
| Effective Pixels |
1,945(H) x 1,097(V) 2.13M |
| Scanning System |
Progressive Scan |
| Min. Illumination |
Color : 0.1Lux, B/W : 0Lux (IR LED on) |
| S / N Ratio |
50dB |
| Video Out |
CVBS : 1.0 Vpp / 75O composite, 720 x 480(N), 720 x 576(P), for installation |
| |
USB : micro USB type B, 1280 x 720 for installation |
| LENS |
| Focal Length (Zoom Ratio) |
3.2~10mm (3.1x) motorized varifocal |
| Max. Aperture Ratio |
F1.6(Wide) ~ F2.9(Tele) |
| Angular Field of View |
H : 109.0°(Wide) ~ 33.2°(Tele) / V : 57.4°(Wide) ~ 18.7°(Tele) / D : 132.0°(Wide) ~ 38.0°(Tele) |
| Min. Object Distance |
0.5m (1.64ft) |
| Focus Control |
Simple focus (Motorized V/F) / Manual, Remote control via network (Manual, Simple focus) |
| Lens / Mount Type |
DC auto iris / Board-in type |
| PAN / TILT / ROTATE |
| Pan / Tilt / Rotate Range |
° ~ 354° / 0° ~ 67° / 0° ~ 355° |
| OPERATIONAL |
| IR Viewable Length |
30m (98.43ft) |
| Camera Title |
Off / On (Displayed up to 85 characters) |
| - W/W : English / Numeric / Special characters |
| - China : English / Numeric / Special / Chinese characters |
| - Common : Multi-line (Max. 5), Color (Gray / Green / Red / Blue / Black / White), Transparency, Auto scale by resolution |
| Day & Night |
Auto (ICR) / Color / B/W / External / Schedule |
| Backlight Compensation |
Off / BLC / HLC (Masking / Dimming), WDR |
| Wide Dynamic Range |
120dB |
| Contrast Enhancement |
SSDR (Off / On) |
| Digital Noise Reduction |
SSNRV (2D + 3D noise filter) (Off / On) |
| Digital Image Stabilization |
Off / On |
| Defog |
Off / Auto (Input from fog detection) / Manual |
| Motion Detection |
Off / On (8ea, 8point polygonal zones), Handover |
| Privacy Masking |
Off / On (32ea, polygonal zones) |
| - Color : Gray / Green / Red / Blue / Black / White - Mosaic |
| Gain Control |
Off / Low / Middle / High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor (Included mercury & Sodium) |
| Contrast |
Level adjusment |
| LDC (Lens Distortion Correction) |
Off / On (5 levels with min / max) |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (2 ~ 1/12,000sec) |
| Digital PTZ |
24x, Digital PTZ (Preset, Group) |
| Flip / Mirror |
Off / On, Hallway view : 90°/270° |
| Video Analytics |
Tampering, Defocus detection, Motion detection |
| Alarm Triggers |
Motion detection, Video analytics, Network disconnect |
| Alarm Events |
File upload via FTP, E-mail, Notification via E-mail, Local storage (SD/SDHC/SDXC) or NAS recording at event triggers |
| Pixel Counter |
Support |
| NETWORK |
| Ethernet |
RJ-45 (10/100BASE-T) |
| Video Compression Format |
H.265 / H.264 (MPEG-4 part 10/AVC) : Main / Baseline / High, MJPEG |
| Resolution |
1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 800 x 448, 720 x 576, 720 x 480, 640 x 480, 640 x 360, 320 x 240 |
| Max. Framerate |
H.265 / H.264 : Max. 60fps at all resolutions, MJPEG : Max. 30fps |
| Smart Codec |
Manual mode (Area-based : 5ea) |
| WiseStream II |
Support |
| Video Quality Adjustment |
H.265 / H.264, MJPEG : Target Bitrate Level Control |
| Bitrate Control Method |
H.265 / H.264 : CBR or VBR, MJPEG : VBR |
| Streaming Capability |
Multiple streaming (Up to 5 profiles) |
| IP |
IPv4, IPv6 |
| Protocol |
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour |
| Security |
HTTPS(SSL) login authentication, Digest login authentication, |
| |
IP address filtering, User access log, 802.1X authentication (EAP-TLS, EAP-LEAP) |
| Streaming Method |
Unicast / Multicast |
| Max. User Access |
20 users at unicast mode |
| Edge Storage |
SD/SDHC/SDXC 1slot (up to 256GB) |
| - Motion images recorded in the SD/SDHC/SDXC memory card can be downloaded. |
| NAS (Network Attached Storage), Local PC for instant recording |
| Application Programming Interface |
ONVIF profile S/G, SUNAPI (HTTP API), Wisenet Open Platform |
| Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
| Web Viewer |
Supported OS : Windows 7, 8.1, 10, Mac OS X 10.10, 10.11, 10.12 |
| Supported Browser : Google Chrome 63, MS Edge 41,MS Internet Explorer 11, Mozilla Firefox 57 (Window 64bit only), Apple Safari 11 (Mac OS X only) |
| Central Management Software |
SmartViewer, SSM |
| ENVIRONMENTAL |
| Operating Temperature / Humidity |
-40°C ~ +55°C (-40°F ~ +131°F) / Less than 90% RH |
| Storage Temperature / Humidity |
-50°C ~ +60°C (-58°F ~ +140°F) / Less than 90% RH |
| Ingress Protection / Vandal Resistance |
IP66 / IK10 |
| ELECTRICAL |
| Input Voltage / Current |
PoE(IEEE802.3af, Class3) |
| Power Consumption |
Max. 11W, Typical 5W |
| MECHANICAL |
| Color / Material |
Dark gray / Aluminum |
| Dimensions (WxH) |
Ø91.0 x L322.9mm (Ø3.58" x 12.71") |
| Weight |
1,298g (4.25 lb) |
