| System Information |
| CPU |
Multimedia SoC (System-on-Chip) |
| Flash |
128 MB |
| RAM |
256 MB |
| Camera Features |
| Image Sensor |
1/2.8" Progressive CMOS |
| Maximum Resolution |
1920 x 1080 (2MP) |
| Lens Type |
Vari-Focal |
| Focal Length |
f= 2.8 ~ 12 mm |
| Aperture |
F1.4 ~ F2.4 |
| Auto-iris |
DC-iris (P-iris reserved) |
| Field of View |
38° ~ 101° (Horizontal) |
| 21° ~ 63° (Vertical) |
| 40° ~ 122° (Diagonal) |
| Shutter Time |
1/5 sec. to 1/32,000 sec. |
| WDR Technology |
WDR Enhanced |
| Day/Night |
Removable IR-cut filter for day & night function |
| Minimum Illumination |
0.08 Lux @ F1.4 (Color) |
| 0.001 Lux @ F1.4 (B/W) |
| Pan/Tilt/Zoom Functionalities |
ePTZ: |
| |
48x digital zoom (4x on IE plug-in, 12x built in) |
| On-board Storage |
Slot Type: SD/SDHC/SDXC card slot |
| Seamless Recording |
| Video |
| Compression |
H.264 & MJPEG |
| Maximum Frame Rate |
30 fps@ 1920x1080 |
| In both compression modes |
| Maximum Streams |
4 simultaneous streams |
| S/N Ratio |
49 dB |
| Dynamic Range |
70 dB |
| Video Streaming |
Adjustable resolution, quality and bitrate |
| Smart Stream II |
| Image Settings |
Time stamp, text overlay, flip & mirror; Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks; Scheduled profile settings, video rotation, 3DNR, defog, lens profile |
| Audio |
| Audio Capability |
Two-Way Audio (full duplex) |
| Compression |
G711, G726 |
| Interface |
External microphone input |
| External line output |
| Network |
| Users |
Live viewing for up to 10 clients |
| Protocols |
IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X, UDP, ICMP, ARP, SSL, TLS |
| Interface |
10 Base-T/100 Base-TX Ethernet (RJ-45) |
| *It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard. |
| ONVIF |
Supported, specification available at www.onvif.org |
| Intelligent Video |
| Video Motion Detection |
Five-window video motion detection |
| VCA* |
Line crossing detection, field detection, loitering detection |
| Alarm and Event |
| Alarm Triggers |
Motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, camera tampering detection, audio detection |
| Alarm Events |
Event notification using digital output, HTTP, SMTP, FTP, NAS server and SD Card |
| File upload via HTTP, SMTP, FTP, NAS server and SD card |
| General |
|
| Connectors |
RJ-45 cable connector for 10/100 Network/PoE connection |
| Audio input |
| Audio output |
| DC 12V power input |
| AC 24V Power input |
| Digital input*3 |
| Digital output*1 |
| BNC output |
| RS485 |
| LED Indicator |
System power and status indicator |
| Power Input |
DC 12V |
| AC 24V |
| IEEE 802.3af PoE Class 0 |
| Power Consumption |
Max. 6.8 W |
| Dimensions |
193 (D) x 70 (W) x 61 (H) mm |
| Weight |
626 g |
| Safety Certifications |
CE, LVD, FCC Class B, VCCI, C-Tick, UL |
| Operating Temperature |
Starting Temperature: 0°C ~ 50°C (32°F ~ 122°F ) |
| Working Temperature: -10°C ~ 50°C (14°F ~ 122°F ) |
| Humidity |
90% |
| Warranty |
36 months |
| System Requirements |
| Operating System |
Microsoft Windows 8/7/Vista/XP/2000 |
| Web Browser |
Mozilla Firefox 7~43 (streaming only) |
| Internet Explorer 7/8/9/10/11 |
| Other Players |
VLC: 1.1.11 or above |
| Quicktime: 7 or above |
| Included Accessories |
| CD |
User's manual, quick installation guide, Installation Wizard 2, VAST |
| Others |
Quick installation guide, mounting bracket, screw pack, Lens |
