Axis M3046 V IP HD Dome Kamera

Özellikler

Network surveillance outdoor dome camera
dustproof / waterproof / vandal-proof
Color ( Day&Night )
4 MP 2688 x 1520
M12 mount
fixed iris,fixed focal
HDMI
10/100 MPEG-4,MJPEG,H.264,PoE

Teknik Özellikler

Video Input

Camera Mechanical Design : Fixed dome

Camera Type : Network surveillance camera

Color or B&W : Color

Connectivity Technology : Wired

Day & Night Functionality : Yes

Digital Video Capture Resolution : 1280 x 720 , 1920 x 1080 , 2688 x 1520 , 320 x 240

Digital Video Format : H.264 , MJPEG , MPEG-4

Features : Active tampering alarm , AXIS Video Hosting System (AVHS) , Backlight compensation , Brightness control , Contrastcontrol , Digital PTZ function , Image mirror , ONVIF support , Password protection , Privacy Mask Function , Progressive scanning , Sharpness control , Text stamp , Variable Bitrate (VBR) , Video Motion Detection Technology , White balance , Wide Dynamic Range (WDR) , Zipstream technology

Frame Rate : 60 frames per second

Max Digital Video Resolution : 2688 x 1520

Panning Range (degree) : -177 to +177

Shutter Speed (Max) : 1/32500 sec

Shutter Speed (Min) : 1/5 sec

Supported Video Signals : HDMI

Tilting Range (degree) : -65 to +65

Optical Sensor

Optical Sensor Type : CMOS

Sensor Size : 1/3"

Sensor Size (metric) : 8.5 mm ( 1/3" )

Total Pixels : 4,000,000 pixels

Networking

Network Interface : Ethernet 10Base-T/100Base-TX

Network Protocols : ARP , Bonjour , CIFS , DDNS , DHCP , DNS , FTP , HTTP , HTTPS , ICMP , IGMP , IPv4 , IPv6 , NTP , QOS , RTCP , RTP , RTSP , SFTP , SMB , SMTP , SNMP 1 , SNMP 2c , SNMP 3 , SOCKS , SSH , SSL , TCP/IP , TLS , UDP/IP , UPnP

Environmental Parameters

Humidity Range Operating : 15 - 85% (non-condensing)

Max Operating Temperature : 104 °F

Min Operating Temperature : 32 °F

Header

Brand : Axis

Compatibility : PC

Manufacturer : Axis Communications

Model : M3046-V

Packaged Quantity : 1

Product Line : AXIS

Lens System

Angular Field of View (H, min, degree) : 128

Angular Field of View (V, min, degree) : 69

Focal Length Control : Fixed focal

Lens Aperture : F/2.2

Lens Iris : Fixed iris

Lens Mount : M12 mount

Max Focal Length : 2.4 mm

Miscellaneous

Color : White

Color Category : White

Compliant Standards : AS/NZS CISPR 22 Class B , EN 60950-1 , EN 61000-6-1 , EN 61000-6-2 , EN55024 , FCC Part 15 B Class A , ICES-003 Class B , IEC 60950-1 , IEC 62262 IK08 , IP42 , KCC , RCM , UL 60950-1 , VCCI Class B

Power Device

Power Consumption Operational : 3.2 Watt

Service

Support Details Full Contract Period : 3 years

Support Details Type : Limited warranty

Digital Camera

Supported Flash Memory : microSD Card , microSDHC Card , microSDXC Card

Dimensions & Weight

Depth : 4 in

Height : 2.2 in

Weight : 6.35 oz

Width : 4 in
