| Camera |
| Image Sensor | 1/1.8” 4Megapixel progressive scan CMOS |
| Effective Pixels | 2688 (H) × 1520 (V) |
| RAM/ROM | 512 MB/128 MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual, 1/3 s–1/100000 s |
| Minimum Illumination | 0.002 Lux@F1.6 |
| IR Distance | Distance up to 50 m (164 ft) |
| IR On/Off Control | Auto/Manual |
| IR LEDs | 1 |
| Lens |
| Lens Type | Fixed-focal |
| Mount Type | Board-in |
| Focal Length | 2.8 mm, 3.6 mm, 6.0 mm |
| Max. Aperture | F1.6 |
| Angle of View | H: 113°, V: 60°/H: 89°, V: 48°/H: 56°, V: 31° |
| Aperture Type | Fixed |
| Close Focus Distance | 1.3 m (4.27 ft)/1.9 m (6.23 ft)/3.8 m (12.47 ft) |
| DORI Distance | Lens | Detect | Observe | Recognize | Identify |
| 2.8mm | 58m(190ft) | 23m(75ft) | 12m(39ft) | 6m(20ft) |
| 3.6mm | 72m(236ft) | 29m(95ft) | 14m(46ft) | 7m(23ft) |
| 6.0mm | 113m(371ft) | 45m(148ft) | 23m(75ft) | 11m(36ft) |
| Pan/Tilt/Rotation |
| Pan/Tilt/Rotation Range | Pan: 0˚–355˚; Tilt: 0˚–75˚; Rotation: 0˚–355˚ |
| Artificial Intelligence |
| Face Detection | Support face image capture |
| Perimeter Protection | Tripwire, intrusion (Recognition of vehicle and people), fast moving, loitering detection, parking detection and people gathering |
| People Counting | Support Line crossing/Region/Queueing people counting; Support 4 accesses independent detection, 4 areas independent detection |
| General Intelligence |
| Event Trigger | Motion detection, Video tampering , Scene changing, Network disconnection , IP address conflict, Illegal Access,Storage anomaly |
| General Intelligence | Object Abandoned/Missing |
| Heat Map | Yes |
| Video |
| Compression | H.265,H.264,H.264B,H.264H, |
| MJPEG (sub stream) |
| Smart Codec | Yes |
| Streaming Capability | 3 Streams |
| Resolution | 2688 × 1520/2560 × 1440/2304 × 1296/1080P (1920 × 1080)/1.3M (1280 × 960)/720P (1280 × 720)/D1 (704 × 576/704 × 480)/VGA (640 × 480)/CIF (352 × 288/352 × 240) |
| Frame Rate | Main Stream: 2688 × 1520 (1 fps–25/30 fps) |
| 2560 × 1440 (1 fps–25/30 fps) |
| 1920 × 1080 (1 fps–50/60 fps) |
| Bit Rate Control | CBR/VBR |
| Bit Rate | H.264:32 Kbps - 8192Kbps |
| H.265: 19kBPS - 8192 Kbps |
| Day/Night | Auto (ICR) / Color / B / W |
| BLC Mode | BLC / HLC / WDR(120dB) |
| White Balance | Auto / Natural / Street Lamp / Outdoor / Manual |
| Gain Control | Auto / Manual |
| Noise Reduction | 3D DNR |
| Motion Detection | Off / On (4 zone rectangle) |
| Region of Interest | Off/On (4 zone) |
| Electronic Image Stabilization (EIS) | N/A |
| Smart IR | YES |
| Defog | YES |
| Flip | °/90°/180°/270° |
| Mirror | Off/On |
| Privacy Masking | Off/On (4 area rectangle) |
| Audio |
| Compression | G.711a , G.711Mu , G.726, AAC, G.723 |
| Network | |
| Ethernet | RJ-45 (10/100Base-T) |
| Protocol | IPv4;IPv6;HTTP;HTTPS;TCP;UDP;ARP;RTP;RTSP;RTCP;RTMP;SMTP;FTP; |
| SFTP;DHCP;DNS;DDNS;QoS;UPnP;NTP;Multicast;ICMP;IGMP;NFS;PPPoE;802.1x;SNMP |
| Interoperability | ONVIF (Profile S/Profile G/Profile T) CGI, Milstone, Genetec, P2P |
| Streaming Method | Unicast / Multicast |
| Max. User Access | 20 users |
| Edge Storage | NAS:FTP:SFTP |
| Micro SD card 256 GB |
| Web Viewer | IE (versions newer than IE8), Chrome, |
| Firefox, Safari (versions newer than Safari 12) |
| Management Software | Smart PSS,DSS,DMSS |
| Smart Phone | iOS, Android |
| Certifications |
| Certifications | CE-LVD: EN60950-1 |
| CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU |
| FCC: 47 CFR FCC Part 15, Subpart B |
| UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07 |
| Interface |
| Audio Interface | 1/1 channel In / Out |
| RS485 | N/A |
| Alarm | 1 channel In : 5mA 5V DC |
| | 1 channel Out : 300mA 12V DC |
| Electrical |
| Power Supply | DC12V (±30%), PoE (802.3af) (Class 0) |
| Power Consumption | <6.1W |
| Environmental |
| Operating Conditions | -30° C to +60° C (-22° F to +140° F)/Less than 95% RH |
| Storage Consumption | -30° C to +60° C (-22° F to +140° F)/Less than 95% RH |
| Ingress Protection | IP67 |
| Vandal Resistance | IK10 |
| Construction |
| Casing | Metal |
| Dimensions | Φ122.0 mm × 88.9 mm (4.80” × 3.50”) |
| Net Weight | 0.47 kg (1.04 lb) |
| Gross Weight | 0.63 kg (1.39Ib) |
