| Camera |
| Image Sensor |
1/3" Progressive Scan CMOS |
| Minimum Aydınlatma |
Color: 0.01 Lux @(F1.2, AGC ON), 0.018Lux @ (F1.6, AGC ON) |
| Slow shutter |
support |
| Objektif Hızı |
1/3 s to 1/100, 000 s |
| Lens |
Horizontal field of view: 98° to 28° |
| Vertical field of view: 51° to 16° |
| Diagonal field of view: 115° to 32° |
| Lens Mount |
φ14 |
| Ayarlanan Aralık |
Pan: 0° to 355°, tilt: 0°to 70°, rotation: 0° to 360° |
| Day& Night |
IR Cut Filter |
| Wide Dynamic Range |
120 dB |
| Dijtal Gürültü Azaltma |
3D DNR |
| Compression Standard |
| Video Compression |
H.265+/H.265/H.264+/H.264/MJPEG |
| H.264 Türü |
Baseline Profile/Main Profile/High Profile |
| Video bit rate |
32Kbps~8Mbps |
| Çift Akış |
Yes |
| Image |
| Max. Image Resolution |
2560 × 1440 |
| Ana Akış |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) |
| 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Çerçeve Hızı |
50Hz: 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720) |
| 60Hz: 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720) |
| Görüntü İyileştirme |
BLC, 3D DNR |
| Image Settings |
Brightness, saturation, contrast, sharpness are adjustable via web browser or client software |
| BLC |
Support |
| Gündüz / Gece Anahtarı |
Day, night, auto, scheduled |
| Network |
| Network Storage |
microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR |
| Alarm Trigger |
Motion detection, tampering alarm, HDD full, HDD error, network disconnected, IP address conflicted, illegal login |
| Protokoller |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
| General Function |
One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy |
| mask, Watermark, IP address filtering |
| System Compatibility |
ONVIF (Profile S, Profile G),ISAPI |
| Interface |
| Dahili Depolama |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Reset Butonu |
Yes |
| General |
| Operating Conditions |
-30 °C to 50 °C (-22 °F to 122 °F), humidity: 95% or less (non-condensing) |
| Power Supply |
12 VDC ± 25%, PoE (802.3af Class3) |
| GÜç Tüketimi |
-Z: 12 VDC, 0.8 A, Max: 10 W; PoE: (802.3af, 36 V to 57 V), 0.35 A to 0.2 A, Max: 12 W |
| -V: 12 VDC, 0.5 A, Max: 6 W; PoE: (802.3af, 36 V to 57 V), 0.22 A to 0.14 A, Max: 8 W |
| Impact Protection |
IK10 |
| Weather Proof |
IP67 |
| IR Range |
Up to 30m |
| Boyutlar |
Camera:? 141 mm × 99.6 mm (? 5.6" × 3.9") |
| With package: 140 mm × 140 mm × 154 mm (5.5" × 5.5" × 6.1") |
| Ağırlık |
Camera: approx. 820 g (1.8 lb.) |
| With package: approx. 1200 g (2.6 lb.) |
