Grundig GCI K1523V IP HD Dome Kamera
Özellikler
- 2 Megapixel IP Camera with Full HD 1080P real time video streaming
- 3 Way Axis Gimbal, wall mountable
- Vandal Resistant Dome (IK10)
- Weatherproof Outdoor Installation (IP66)
- H.264 & MJPEG compression modes (max. 25 fps)
- ONVIF protocol support
- SD/SDHC memory card slot for alarm and schedule image recording
- Bidirectional Audio Support
- Power Input AC24V/DC12V and PoE
Teknik Özellikler
| Image Sensor | 1/2.7" CMOS Omnivision, 2 Megapixel |
| Pixels - Total | 1920(H) x 1080(V) |
| Col/B&W | On/Off/Auto, IR-cut filter removable (ICR) |
| Sensitivity Colour | 0.5 Lux @ F1.2 (IRE50), 0.2 Lux @ F1.2 (IRE30) |
| Sensitivity B&W | 0.1 Lux @ F1.2 (IRE50), 0.02 Lux @ F1.2 (IRE30) |
| Lens Drive Type | Auto iris (DC) |
| Lens Focal Length | 3 ~ 9 mm |
| Viewing Angle | approx. 104°(H) ~ 33°(V) |
| BLC | On/Off |
| WDR | High/Medium/Low |
| Digital Noise Reduction (DNR) | On/off 2D/3D Noise Filter |
| Motion Detection | On/ Off/ Sensitivity/ Area setting |
| Tampering Alarm | On/Off |
| Privacy zones | 5 zones, rectangle |
| White Balance | ATW, AWB, Manual |
| Digital Zoom | Yes |
| Shutter Speed | 1 sec to 1/10,000 sec |
| Alarm Inputs | 1 |
| Alarm Outputs | 1 |
| Web Browser | MS Internet Explorer 6.0 (or higher), Firefox, Google Chrome, Safari |
| Number of Clients | Up to 20 user |
| Video Compression | H.264, MJPEG |
| Video Resolution | Full HD 1080p/ SXGA/ HD 720p/ XGA/SVGA/ 4CIF/ VGA/ CIF |
| Video Streaming | Quad stream: max.: H.264+H.264+H.264+H.264 or H.264+H.264+H.264+MJPEG |
| Network Protocol | IPv4/v6, TCP/IP, UDP, RTP, RTSP, HTTP, HTTPS, DHCP, PPPoE, UPnP, SMTP, ICMP, IGMP, SNMP, IEEE802.1x, QoS, ONVIF |
| SD memory | supports up to 32 GB capacity of micro SD/SDHC memory |
| Alarm Event | Alarm Input, Motion Detection or Schedule: Image transfer or alarm message by FTP, |
| Image transfer or alarm message by E-mail, recording on SD-card, enable alarm output and send HTTP notification | |
| Audio Compression | G.726, G.711 |
| LED Indicator | Power, link, active |
| Video Outputs | 1Vpp, BNC |
| Input/Output sockets | Video Out(BNC), Power(3-Pin Term), RJ-45, Micro SD Card Slot, |
| Alarm Terminal 4-Pin (Alarm In 2-Pin, Alarm Out 2-Pin photo relay 300VDC/AC), Audio (4-Pin) | |
| Firmware Upgrade | Firmware upgrade by Web Browser |
| Configuration | Upload & Download configuration on remote PC |
| Protection Rating | IP66 |
| Operating Temperature | -10°C ~ +50°C |
| Humidity | 10 ~ 90% no condensation |
| Regulation | CE, FCC, RoHS Compliant |
| Supply Voltage | 12 VDC / 24 VAC / PoE IEEE 802.3af |
| Power Consumption | 5 W |
| Weight | 0.8 kg |
| Dimensions w*h*d | Ø 151 x 131 mm |
Teknik Kısa
Çözünürlük : 2MP (1080P)
Ses : Var
Depolama : Var
