| Camera |
| Image Sensor | 1/3" Progressive Scan CMOS |
| Min. Illumination | Color: 0.005 Lux @ (F1.2, AGC ON), 0.009 Lux @ (F1.6, AGC ON), 0 Lux with IR |
| Shutter time | 1/3 s to 1/100,000 s |
| Slow shutter | Yes |
| Lens | 2.0/2.8/4/6/8 mm fixed lens |
| Lens Mount | M12 |
| Adjustment Range | Pan: -30° to +30°, Tilt: 0° to 75°, Rotate: 0° to 360° |
| Day& Night | IR Cut Filter |
| Wide Dynamic Range | 120 dB |
| Digital noise reduction | 3D DNR |
| Compression Standard |
| Video Compression | H.265/H.264/MJPEG |
| H.264 code profile | Main Profile/High Profile |
| Video bit rate | 32Kbps~16Mbps |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM |
| Audio bit rate | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2) |
| Triple Streams | Yes |
| Image |
| Max. Image Resolution | 2304 × 1296 |
| Sub Stream | H.265/H.264/MJPEG |
| 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) |
| 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Third Stream | H.265/H.264 |
| 50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288) |
| 60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240) |
| Image Enhancement | BLC, 3D DNR |
| Image Settings | Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
| Target Cropping | No |
| BLC | Support |
| 3D DNR | Yes |
| ROI | Yes |
| Picture Overlay | No |
| Day/Night Switch | Day/Night/Auto/Schedule |
| Network |
| Network Storage | microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR |
| Alarm Trigger | Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
| General Function | One-key recovery, Anti-Flicker, three streams, heartbeat, mirror, password protection, video |
| | mask, Watermark, IP address filtering |
| System Compatibility | ONVIF (Profile S, Profile G), ISAPI |
| Interface |
| Communication Interface | 1 RJ45 10M/100M Ethernet port |
| On-board storage | Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Reset Button | Yes |
| Audio |
| Audio Sampling Rate | 8 kHz/16 kHz/32 kHz/44.1 kHZ/48 kHz |
| Smart Feature-set |
| Behavior Analysis | Line crossing detection, Intrusion detection, Unattended baggage detection, Object removal detection |
| Recognition | Face Detection |
| General |
| IR Range | up to 30 m |
| Operation Condition | -30 °C to 60 °C (-22 °F to 140 °F), humidity less than 95% or less (non-condensing) |
| Power Supply | 12 VDC ± 25%, PoE (802.3af Class3) |
| Power Consumption | 12 V DC ± 25%, 0.5 A, max. 6 W |
| PoE: (802.3af,36V-57V), 0.2A to 0.13A, Max:7.5W |
| Impact Protection | IK08 Protection Level |
| Weather Proof | IP66 |
| Dimensions | Camera: Φ 110 mm × 57.4 mm (4.3″ × 2.3″), with base: Φ 110 mm × 69.4 mm (4.3″ × 2.7″) |
| With package: 60 mm × 100 mm × 250 mm (2.4″ × 4.0″ × 9.8″) |
| Weight | Camera: Approx. 580 g (1.3 lb.) |
| With package: 860 g (1.9 lb) |
