Hikvision DS 2PT5306IZ DE IR IP PTZ Kamera

Özellikler

Three 1/2.8" progressive scan CMOS
UP to 3-ch 1920 × 1080@30fps resolution
Min. illumination:
Color: 0.005 Lux @(F1.6, AGC ON)
B/W: 0.001 Lux @(F1.6, AGC ON)
0 Lux with IR
Horizontal FOV: 80.7° × 3
Vertical FOV: 43.5°
Three flexible cameras are adjustable along a circular track, slide range: 0° to 270°
Up to 30 m IR radius
IP66

Teknik Özellikler

Panoramic Camera
Image Sensor	Three 1/2.8" progressive scan CMOS
Min. Illumination	Color: 0.005 Lux @(F1.6, AGC ON)
	B/W: 0.001 Lux @(F1.6, AGC ON)
	0 Lux with IR
Lens	4 mm
Angle of View	Horizontal field of view: 80.7° × 3
Angle of View	Vertical field of view: 43.5°
Main Stream	Main stream:(Sub-stream not enabled)
	50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
	60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
	Main stream:(Sub-stream enabled)
	50 Hz: 20 fps (1920 × 1080, 1280 × 960, 1280 × 720)
	60 Hz: 20 fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub Stream	50 Hz: 20 fps (704 × 576, 640 × 480, 352 × 288)
Sub Stream	60 Hz: 20 fps (704 × 480, 640 × 480, 352 × 240)
Image Compression	Main stream: H.265/H.264
	Sub-stream: H.265/H.264/MJPEG (MJPEG is only supported by channel 1)
	H.264 with Main Profile/High Profile, H.265 with Main Profile
HLC	Support
Shutter Time	1/1 s to 1/30,000 s
Day& Night	ICR
Basic Event Detection:	Motion Detection, Video Tampering Detection, Exception
Smart Image Enhancement:	Digital WDR/HLC/BLC/3D DNR/Defog/Regional Exposure
System Function
IR	10 m
Smart Detection	Audio Exception Detection, Intrusion Detection, Line Crossing Detection
Alarm
Alarm I/O	1-ch alarm input and 1-ch alarm output
Input & Output
Audio Input	1-ch audio input
Audio Output	1-ch audio output
Network
Audio compression	G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2
Protocol	IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, DHCP, PPPoE, Bonjour
Application programming	Open-ended, support ONVIF, ISAPI, and CGI, support HIKVISION SDK and Third-Party Management Platform
System Integration
User/Host Level	Up to 32 users,3 Levels: Administrator, Operator and User
Security Measures	User authentication (ID and PW); Host authentication (MAC address); IP address filtering
Web Browser	IE 8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51
Ethernet	1 RJ45 10 M/100 M Ethernet
Onboard Storage	Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB
General
Power supply	12 VDC & PoE+ (802.3 at, class 4)
Power supply	Max.21 W (Max. 7 W for IR)
Working temperature	-40°C to 70°C (-40°F to 158°F), with heater on
Working humidity	≤ 90%
Material	PC & Aluminum alloy
Protection Level	IP66, TVS 4000V Lightning Protection, Surge Protection and Voltage Transient Protection
Dimensions (W×D×H)	Φ 271.3 mm × 164 mm (Φ 10.68" × 6.46")
Weight	Approx. 2.5 kg (5.51 lb.)
