Dahua TPC-SD8641B IP Termal Hybrid Speed Dome Kamera

Özellikler

Vanadium oxide uncooled focal plane detector.
1/1.8" 4 megapixel progressive scan CMOS.
Visible lens offers 45× optical zoom.
Offers various AI functions such as boat, engineering truck and heat detection, tripwire, intrusion, target filtering, and alarm linkage, such as email alarm and external alarm.
Faster and more precise when locating and capturing targets in light of the three dimensional positioning function.
Auto rain-sensing for a clear view and a longer service life of the wiper.
SD card storage and automatic network replenishment.
IR illumination distance: 150 m.
7/2 Alarm in/out.

Teknik Özellikler

Thermal
Detector Type	Vanadium oxide uncooled focal plane detector
Effective Pixels	640 (H) × 512 (V)
Pixel Pitch	17 μm
Spectral Range	8 μm–14 μm
Sensitivity (NETD)	<35 mK (@f/1.0)
Focal Length	25 mm; 35 mm; 50 mm
Field of View	25 mm: H: 24.6°; V: 19.8°
	35 mm: H: 17.6°; V: 14.1°
	50 mm: H: 12.4°; V: 10°
Thermal Focus Control	Fixed-focal
Close Focus Distance	25 mm: 1 m (3.28 ft)
	35 mm: 1 m (3.28 ft)
	50 mm: 1 m (3.28 ft)
Detection Distance①	25 mm: Vehicle: 1,961 m (6,433.73 ft)
	Human: 735 m (2,411.42 ft)
	35 mm: Vehicle: 2,745 m (9,005.91 ft)
	Human: 1,029m (3,375.98 ft)
	50 mm: Vehicle: 3,922 m (12,867.45 ft)
	Human: 1,471 m (4,826.12 ft)
Recognition Distance②	25 mm: Vehicle: 490 m (1,607.61 ft)
	Human: 189 m (620.08 ft)
	35 mm: Vehicle: 686 m (2,250.66 ft)
	Human: 265 m (869.42 ft)
	50 mm: Vehicle: 980 m (3,215.22 ft)
	Human: 378 m (1,240.16 ft)
Identification Distance③	25 mm: Vehicle: 245 m (803.81 ft)
	Human: 95 m (311.68 ft)
	35 mm: Vehicle: 343 m (1,125.33 ft)
	Human: 132 m (433.07 ft)
	50 mm: Vehicle: 490 m (1,607.61 ft)
	Human: 189 m (620.08 ft)
Note: ①Detection Distance: Detects objects, but cannot recognize their characteristics. Detected objects only cover a small amount of pixels (objects must cover more than 3.6 pixels of the image). ②Recognition Distance: Classifies objects into general categories, such as human, vehicle, and building (the object must cover more than 14 pixels of the image). ③Identification Distance: Classifies objects into specific categories based on their characteristics, such as soldier, pickup truck, and gas station (the object must cover more than 28 pixels of the image).
Digital Detail Enhancement (DDE)	Yes
Digital Zoom	19 levels
Thermal AGC	Auto/Manual
Thermal Noise Reduction	2D NR/3D NR
Image Flip	180°; Mirror
Color Palettes	18 (white hot/black hot/fusion/rainbow/golden autumn/midday/iron red/amber/jade/sunset/icefire/painting/pomegranate/emerald /spring/summer/autumn/winter)
Visible
Image Sensor	1/1.8" CMOS
Max. Resolution	2688 (H) × 1520 (V)
Pixel	4 MP
Horizontal Definition	≥1200 TVL
Min. Illumination	Color: 0.001 lux@F1.4
	Black & white: 0.0001 lux@F1.4
	0 lux (IR on)
Visible AGC	Auto/Manual
Visible Noise Reduction	2D NR/3D NR
S/N Ratio	≥55 dB
White Balance	Auto; manual; indoor; outdoor; tracking; sodium lamp; street lamp; natural
Defog	Electronic defog
Visible Image Stabilization	Electronic Image Stabilization
Electronic Shutter Speed	1 s–1/30,000 s (auto/manual)
BLC	Yes
WDR	Yes
HLC	Yes
Digital Zoom	Yes
Day/Night	Auto (ICR); Color; B/W
Iris Control	Auto
Image Flip	Yes
Exposure Compensation	Yes
Visible Focus Control	Auto/semi-auto/manual
Focal Length	5.5 mm–248 mm
Zoom Speed	<7 s
Field of View	H: 62.32°–1.71°
	V: 36.55°–1.0°
Close Focus Distance	0.5 m–2 m (1.64 ft–6.56 ft)
Optical Zoom	45×
Aperture	F1.4–F4.5
Illuminator On/Off Control	Auto/Manual
Illumination Distance	150 m (492.13 ft)
Audio and Video
Video Compression	H.265; H.264; H.264H
Resolution	Thermal:
	Main stream: 1280 × 1024; 1280 × 960 ; 720p (1280 × 720); 400× 300; 1280 × 960 (default)
	Sub stream: 640 × 512; 640 × 480; 400 × 300; 400 × 300 (default)
	Visible:
	Main stream: 4 MP (2688 × 1520); 4 MP (2560 × 1440); 1080p (1920 × 1080); 720p (1280 × 720); D1 (704 × 576); 1080p (default)
	Sub stream: D1 (704 × 576); CIF (352 × 288); D1 (704 × 576) (default)
Video Frame Rate	Thermal:
	50 Hz: (main stream) 1 fps–25 fps adjustable, 25 fps by
	default; (sub stream) 1 fps–25 fps adjustable, 15 fps by default
	default
	60 Hz: (main stream) 1 fps–30 fps adjustable, 30 fps by
	default; (sub stream) 1 fps–30 fps adjustable, 15 fps
	by default
	Visible:
	50 Hz: (main stream) 1 fps–25 fps adjustable, 25 fps by
	default; (sub stream) 1 fps–25 fps adjustable, 15 fps by
	default
	60 Hz: (main stream) 1 fps–30 fps adjustable, 30 fps by
	default; (sub stream) 1 fps–30 fps adjustable, 15 fps
	by default
Audio Compression	G.711a; G.711mu; AAC
Image Encoding Format	JPEG
PTZ
Pan/Tilt Range	Pan: 0° to +360°
	Tilt: –27° to +90°
Manual Control Speed	Pan: 0.1°/s to 200°/s
	Tilt: 0.1°/s to 120°/s
Preset Speed	Pan: 0.1°/s to 240°/s
	Tilt: 0.1°/s to 200°/s
Preset	300
Tour	8 (up to 32 presets per tour)
Pattern	5
Scan	5
Power-off Memory	Yes
Privacy Masking	4 by default
Idle Motion	Preset; Pattern; Tour; Scan; Horizontal Rotation
Timing Task	Preset; Pattern; Tour; Scan; Horizontal Rotation
Position Display	On/Off
Wiper	Auto rain-sensing. Supports setting wiper running times, frequency, and period.
3D Positioning	Yes
Function
Two-way Audio	Yes
Network Protocol	HTTPS; HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; SNMP; QoS; UPnP; NTP
Region of Interest (RoI)	Yes (customizable)
Storage	Micro SD card
Micro SD Card (Max.)	512 GB
Interoperability	ONVIF; CGI; Dahua SDK
Browser	IE: IE8 and later
	Chrome: 42 and earlier
	Firefox: 42 and earlier
User/Host	Up to 20 (total bandwidth: 64 MB)
Security
User Management	Up to 20 users; supports multi-level user permissions (2 levels): management group and user group
Malfunction Detection	Network disconnection detection; IP conflict detection; memory card state detection; memory space detection
PIP	Yes
Intelligence
Heat Detection	Yes
Cold/Hot Spot Trace	Yes
IVS (Perimeter Protection)	Yes. Supports tripwire and intrusion.
Target Distinction	Human/Vehicle Classification
Target Tracking	Yes
Target Filtering	Yes
Smoking Detection	Yes
Call Detection	Yes
Smoke Detection	Yes
Boat Detection	Yes
Engineering Truck Detection	Yes
Panoramic PTZ	Yes
Port
Analog Output	1 × CVBS output; BNC port
Network Port	1 × RJ-45 (10/100 Base-T)
Alarm Input	7
Alarm Output	2
Audio Input	1
Audio Output	1
RS-485	1
Power
Power Supply	36 VDC/5A ± 25%
Power Consumption	Basic: 30 W
	Max: 50 W (illuminator)
Environment
Operating Temperature	–40 °C to +70 °C (–40 °F to +158 °F)
Operating Humidity	≤95%
Storage Temperature	–50 °C to +80 °C (–58 °F to +176 °F)
Physical Characteristics
Protection	IP66
Reliability	Surge protection: 6 kV
	Air discharge: 15 kV
	Contact discharge: 8 kV
Structure
Product Dimensions	300 mm × 300 mm × 500 mm (11.81" × 11.81" × 19.69") (L × W × H)
Packaging Dimensions	435 mm × 435 mm × 666 mm (17.13" × 17.13" × 26.22") (L × W × H)
Net Weight	≤13 kg (28.66 lb)
Gross Weight	≤16 kg (35.27 lb)
Heat Detection Distance
Focal Length	25 mm	35mm	50 mm
Heat Detection Distance (Recommended)	774 m (2,539.37 ft)	1,084 m (3,556.43 ft)	1,548 m (5,078.74 ft)
Heat Detection Distance (Max.)	1,548 m (5,078.74 ft)	2,167 m (7,109.58 ft)	3,096 m (10,127.48 ft)
Note: The table displays the measured distances obtained from using the target size 2 m × 2 m for testing in an environment where the temperature is 23 °C and the relative humidity is below 60%. The table is for reference only. The distances within it are subject to actual conditions including atmospheric conditions, target size, the installation site, and more.
Perimeter Protection
Focal Length	25 mm	35mm	50 mm
Perimeter Protection Distance (Human)	141 m (462.60 ft)	198 m (649.61 ft)	283 m (928.48 ft)
Perimeter Protection Distance (Vehicle)	396 m (1,299.21 ft)	554 m (1,817.59 ft)	792 m (2,391.73 ft)
Note: The table displays the optimal distance obtained from testing in an environment where the temperature is 23 °C and the relative humidity is below 60%. The table is for reference only. The distances within it are subject to actual conditions including atmospheric conditions, target size, the installation site, and more.
