| OVERVIEW |
| Accuracy |
| ±2°C (±3.6°F) or ±2% of reading |
| Color alarm (isotherm) |
| •Above •Below •Interval •Condensation (moisture/humidity/dewpoint) •Insulation |
| Difference Temperature |
| Yes |
| Display Technology |
| IPS |
| Focal Length |
| 17 mm (0.67 in.), 24° |
| Housing material |
| PCABS with TPE, magnesium |
| IR Resolution |
| 464 × 348 pixels |
| Laser Alignment |
| Position is automatically displayed on the infrared image |
| Laser Pointer |
| Class 2, 0.05–40 m (0.16–131 ft.) ±1% of measured distance |
| NETD |
| < 40 mk |
| Object Temperature Range |
| -20°C to 120°C (-4°F to 248°F) 0°C to 650°C (32°F to 1202°F) 300°C to 1500°C (572°F to 2732°F) There are no optional ranges |
| Packaging Size |
| 500 × 190 × 370 mm (19.7 × 7.5 × 14.6 in.) |
| Programmable Buttons |
| 2 |
| Resolution |
| 464 × 348 pixels (VGA) |
| Screening |
| 0.5°C (0.9°F) accuracy at 37°C (98.6°F) with reference |
| Size (L x W x H) |
| Lens horizontal: 140 × 201.3 × 167.3 mm (5.5 × 7.9 × 6.6 in.) |
| Thermal Sensitivity/NETD |
< 40 mK, 24° @ 30°C (86°F)
|
| Warranty |
| http://www.flir.com/warranty/ |
| Text |
| Predefined list or touchscreen keyboard |
| Time Lapse [Infrared] |
| 10 sec to 24 hrs |
| Voice |
| 60 sec. recording added to still images or video via built-in mic (has speaker) or via Bluetooth |
| Weight & Dimensions (without lens) |
| 1.3 kg (2.9 lbs), 140 × 201 × 84 mm (5.5 × 7.9 × 3.3 in) |
| CONNECTIONS & COMMUNICATIONS |
| Audio |
| Microphone and speaker for voice annotation of images |
| Communication Interfaces |
| USB 2.0, Bluetooth, Wi-Fi |
| METERLiNK - Bluetooth |
| Communication with headset and external sensors |
| Remote Control |
| •Using FLIR Tools (using USB cable) •FLIR Tools Mobile (over Wi-Fi) |
| Storage Media |
| Removable SD card |
| USB |
| USB Type-C: data transfer/video/power |
| USB - Standard |
| USB 2.0 High Speed |
| Video Out |
| DisplayPort over USB Type-C |
| METERLiNK |
| Wireless connection (Bluetooth) to: FLIR meters with METERLiNK |
| Setup Commands |
| Local adaptation of units, language, date, and time formats |
| ENVIRONMENTAL |
| EMC |
| •ETSI EN 301 489-1 (radio) •ETSI EN 301 489-17 •EN 61000-6-2 (immunity) •EN 61000-6-3 (emission) •FCC 47 CFR Part 15 Class B (emission) |
| Emissivity Correction |
| Yes, variable from 0.01 to 1.0 or selected from materials list |
| Humidity (Operating and Storage) |
| IEC 60068-2-30/24 hours, 95% relative humidity, 25–40°C (77–104°F)/2 cycles |
| Operating Temperature Range |
| –15°C to 50°C (5°F to 122°F) |
| Radio Spectrum |
| •ETSI EN 300 228 •FCC Part 15.249 •RSS-247 Issue 2 |
| Safety |
| EN/UL/CSA/PSE 60950-1 |
| Storage Temperature Range |
| –40°C to 70°C (-40°F to 158°F) |
| Tripod Mounting |
| UNC 1/4"-20 |
| Shock & Vibration & Encapsulation |
| 25 g / IEC 60068-2-27, 2 g / IEC 60068-2-6 / IP 54; EN/UL/CSA/PSE 60950-1 |
| IMAGING & OPTICAL |
| Aspect ratio |
| 04:03 |
| Auto Rotation |
| Yes |
| Camera software update |
| Use PC software FLIR Tools |
| Color |
| Black |
| Color palettes |
| Iron, Gray, Rainbow, Arctic, Lava, Rainbow HC |
| Detector Type and Pitch |
| Uncooled microbolometer, 17 µm |
| Digital Camera |
| 5 MP, with built-in LED photo/video lamp |
| Digital Camera Focus |
| Fixed |
| Digital Camera FOV |
| 53° × 41° |
| Digital Zoom |
| 1–6× continuous |
| f-number |
| 1.3, 24° |
| Field of View |
| 24° × 18° |
| Field of view match |
| Yes |
| Focus |
| Continuous with laser distance meter (LDM), one- shot LDM, one-shot contrast, manual |
| Frame Rate [Full Window] |
| 30 Hz |
| Gallery |
| Yes |
| Global Positioning System [GPS] |
| Location data automatically added to every still image and first frame in video from built-in GPS |
| Image Adjustment |
| •Automatic •Automatic maximum •Automatic minimum •Manual |
| Image Frequency |
| 30 Hz |
| Image Sketch |
| From touchscreen, on infrared image only |
| Lens |
| 24° |
| Lens Identification |
| Automatic |
| Minimum Focus Distance |
| 0.15 m (0.49 ft.), 24°, Macro mode 71 µm as option to 24° |
| Minimum Focus Distance with MSX |
| 0.5 m (1.64 ft.), 24° |
| Non-Radiometric IR or Visual Video |
| H.264 to memory card |
| Non-radiometric IR video streaming |
| H.264 or MPEG-4 over Wi-Fi MJPEG over UVC or Wi-Fi |
| Picture-in-Picture |
| Resizable and movable |
| Radiometric IR video recording |
| Real-time radiometric recording (.csq) |
| Radiometric IR video streaming |
| Over UVC |
| Spatial resolution (IFOV) |
| 0.90 mrad/pixel, 24° |
| Spectral Range |
| 7.5 - 14 µm |
| Viewfinder |
| No |
| Visual Video Recording |
| H.264 to memory card |
| Color Depth |
| 24 |
| UltraMax |
| Quadruples pixel count; activated in menu and processed in FLIR Tools |
| Video Lamp |
| Built-in LED light |
| Viewing Angle |
| 80° |
| Visual Image |
| Yes |
| Visual Video Streaming |
| Yes |
| MEASUREMENT & ANALYSIS |
| Area measurement information |
| Yes |
| Languages |
| 21 |
| Laser Distance Meter |
| Yes; dedicated button |
| Measurement Corrections |
| Yes |
| Measurement Function Alarm |
| Audible/visual alarms (above/below) on any selected measurement function |
| Measurement Presets |
| •No measurements •Center spot •Hot spot •Cold spot •User preset 1 •User preset 2 |
| Reference Temperature |
| Yes |
| Spotmeter and Area |
| 3 ea. in live mode |
| Automatic hot & cold detection |
| Automatic maximum/minimum markers within area |
| METER DATA |
| Cover Glass Material |
| Dragontrail® |
| Display |
| 4", 640 x 480 pixel touchscreen LCD with auto-rotation |
| POWER |
| Battery operating time |
| Approx. 4 hours at 25°C (77°F) ambient temperature and typical use |
| Battery size (L x W x H) |
| 59 × 66 × 94 mm (2.3 × 2.6 × 3.7 in.) |
| Battery Type |
| Li-ion battery, charged in camera or on separate charger |
| Battery voltage |
| 3.6 V |
| Battery weight |
| 195 g (6.89 oz.) |
| Charging system |
| In camera (AC adapter or 12 V from a vehicle) or two-bay charger |
| Charging Temperature |
| °C to 45°C (32°F to 113°F) |
| Charging Time (using two-bay charger) |
| 3.5 h to 90% capacity, on-screen indicator |
| External Power Operation |
| AC adapter 90–260 V AC (50/60 Hz) or 12 V from a vehicle (cable with standard plug, optional) |
| Power Management |
| Automatic shut-down and sleep mode |
| SHIPPING INFORMATION |
| Packaging |
| Infrared camera with lens, 2 batteries, battery charger, hard transport case, lanyards, front lens cap, power supplies, printed documentation, SD card (8 GB), cables (USB 2.0 A to USB Type-C, USB Type-C to HDMI, USB Type-C to USB Type-C) |
| STORAGE MEDIA |
| Image File Format |
| Standard JPEG with measurement data included |
| Detector Resolution |
| 464 x 348 |
