| Video |
Thermal |
Visible |
| Imaging Device |
Uncooled micro bolometer (320x240) |
1/2.8" 2MP CMOS |
| Resolution |
1280x960, 640x480, 320x240 |
1920x1080, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240 |
| Max. Framerate |
H.265/H.264: Max. 30fps/25fps(60Hz/50Hz) |
| |
MJPEG: Max. 30fps/25fps(60Hz/50Hz) |
| NETD |
＜60mK |
None |
| Pixel Size |
12㎛ |
None |
| Min. Illumination |
None |
Color: 0.05 lux(F1.6, 1/30sec) |
| B/W: 0.005 lux(F1.6, 1/30sec) |
| Video Out |
CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation |
| USB : Micro USB Type B, 1280x720 for installation |
| Lens |
| Focal Length (Zoom Ratio) |
4.7mm fixed focal |
4mm fixed focal |
| Max. Aperture Ratio |
F1.0 |
F1.6 |
| Angular Field of View |
H: 50.0˚, V: 36.4˚, D: 65.3˚ |
H: 87.6, V: 46.4°, D: 104.5° |
| Min. Object Distance |
1m(3.28ft) |
None |
| Focus Control |
Fixed |
| Operational |
| Camera Title |
Displayed up to 85 characters |
| Day & Night |
None |
Auto(ICR) |
| Backlight Compensation |
None |
BLC, WDR, SSDR |
| Wide Dynamic Range |
None |
extremeWDR(150dB) |
| Digital Noise Reduction |
None |
SSNR V |
| Digital Image Stabilization |
Support(built-in gyro sensor) |
| Motion Detection |
8ea, 8point polygonal zones |
| Privacy Masking |
32ea, polygonal zones |
| - Color: Grey/Green/Red/Blue/Black/White |
| - Mosaic |
| Gain Control |
None |
Low / Middle / High |
| White Balance |
None |
ATW / AWC / Manual / Indoor / Outdoor |
| LDC |
None |
Support |
| Electronic Shutter Speed |
None |
Minimum / Maximum / Anti flicker(2~1/12,000sec) |
| Video Rotation |
Flip, Mirror |
| Analytics |
EBT mode : Temperature detection, Blackbody error |
| Normal mode : Directional detection, Motion detection, Enter/Exit, Tampering, Virtual line, Audio detection, Temperature detection |
| *EBT : Estimated Body Temperature |
| Alarm I/O |
Input 1ea / Output 2ea |
| Alarm Triggers |
Analytics, Network disconnect, Alarm input |
| Alarm Events |
File upload via FTP and e-mail |
| Notification via e-mail |
| SD/SDHC/SDXC or NAS recording at event triggers |
| Alarm output |
| Handover (normal mode only) |
| Audio playback |
| Beep alarm (EBT mode only) |
| Audio In |
Selectable(mic in/line in) |
| |
Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm |
| Audio Out |
Line out, Max.output level: 1Vrms |
| Color Palettes |
EBT Mode (thermal face detection) |
None |
| : Whitehot |
| EBT (visible face detection) & Normal mode |
| : Whitehot, Blackhot, Rainbow, Rainbow2, Sepia, Red, Iron, Custom |
| Radiometry |
| Temperature Detect Range |
Estimated body temperature mode |
None |
| : 30~45°C(86°F~113°F) |
| Normal mode |
| : -20~+130°C(-4˚F~+266˚F) |
| Temperature Accuracy |
Estimated body temperature mode |
None |
| : ±0.5°C(±0.3°C with Blackbody) |
| Normal mode |
| : ±5˚C(≤100˚C), ±20%(>100˚C) |
| Temperature Detection |
3ea rectanguler (normal mode) |
None |
| Additional |
Hybrid palettes (normal mode), |
None |
| Spot temperature reading (normal mode) |
| Network |
| Ethernet |
Metal shielded RJ-45(10/100BASE-T), RJ-45(10/100BASE-T) |
| Video Compression |
H.265/H.264: Main/Baseline/High, MJPEG |
| Audio Compression |
G.711 u-law /G.726 Selectable |
| G.726(ADPCM) 8KHz, G.711 8KHz |
| G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps |
| AAC-LC: 48Kbps at 16KHz |
| Smart Codec |
WiseStreamⅡ |
Manual(5ea area), WiseStreamⅡ |
| Bitrate Control |
H.264/H.265: CBR or VBR |
| MJPEG: VBR |
| Streaming |
Unicast(20 users) / Multicast |
| Multiple streaming(Up to 6 profiles) |
| Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, LLDP |
| Security |
HTTPS(SSL) login authentication |
| Digest login authentication |
| IP address filtering |
| User access log |
| 802.1X authentication(EAP-TLS, EAP-LEAP) |
| Device certificate(Hanwha Techwin Root CA) |
| Application Programming Interface |
ONVIF Profile S/T |
| SUNAPI(HTTP API) |
| General |
| Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
| Edge Storage |
Micro SD/SDHC/SDXC 1slot 256GB |
| Memory |
4608MB RAM, 512MB Flash |
| Environmental & Electrical |
| Operating Temperature / Humidity |
EBT mode |
| : +10°C~+35°C(+50°F~+95°F) / Less than 95% RH |
| Normal mode |
| : -10°C~+55°C(+14°F~+131°F) / Less than 95% RH |
| Storage Temperature / Humidity |
-30°C~+60°C(-22°F~+140°F) / Less than 95% RH |
| Input Voltage |
PoE+(IEEE802.3at, Class4), 12VDC |
| Power Consumption |
PoE+: Max. 17.0W, typical 12.5W |
| 12VDC: Max. 14.5W, typical 11.0W |
| Mechanical |
| Color / Material |
White / Aluminum |
| RAL Code |
RAL9003 |
| Product Dimensions / Weight |
135(W)x75(H)x188.5(D)mm, (5.31x2.95x7.42"), 1.7kg(3.77lb) |
