| Camera |
| Image Sensor | 1/3” DIS |
| Signal System | PAL/NTSC |
| Effective Pixels | 976(H)×496(V) |
| Min. Illumination | 0.1 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Shutter Time | 1/50(1/60)s to 1/100,000s |
| Lens | 3.6 mm @ F2.2 (2.8mm, 6mm, 8mm, 12mm optional) |
| Angle of view: 68.4° (3.6 mm) |
| Lens Mount | M12 |
| Adjustment Range | Pan: 0 ± 30°, Tilt: 0 - 75°, Rotation: 0 - 360° |
| Day& Night | IR cut filter with auto switch |
| Horizontal Resolution | 700 TVL |
| Wide Dynamic Range | Digital |
| Synchronization | Internal Synchronization |
| CVBS Output | 1Vp-p composite output (75 Ω/Aviation plug) |
| S/N Ratio | More than 62 dB |
| BLC | On/Off |
| Menu |
| D/N Mode | Auto/ Color/ BW/ Smart |
| AGC | Support |
| Interface |
| Audio In | Built-in Microphone |
| Audio Out | 1-ch audio interface(Aviation plug) |
| Video Out | 1Vp-p composite output (75 Ω/Aviation plug) |
| General |
| Operation Condition | -40 °C - 60 °C (-40 °F - 140 °F) |
| Humidity 90% or less (non-condensing) |
| Power Consumption | 12 V DC ± 10% |
| Weather Proof | IP65 |
| IR Range | Up to 20m |
| Dimension | 97 × 46.6 × 99.5mm (3.82” × 1.83” × 3.92”) |
| Weight | 300 g(0.66 lbs) |
