| Camera |
| WDR (Wide Dynamic Range) | DWDR |
| Image Sensor | 4 MP CMOS image sensor |
| İşaret Sistem | PAL/NTSC |
| Etkin Piksel | 2560 (H) × 1440 (V) |
| Min. Illumination | 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR |
| Shutter Time | 1/25(1/30) s to 1/50,000 s |
| Lens Mount | M12 |
| Ayarlama Aralık | Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360° |
| Day& Night | IR cut filter |
| Video Frame Rate | PAL: 1080p@25fps, 4 MP@25fps |
| NTSC: 1080p@30fps, 4 MP@30fps |
| HD Video Çıkışı | 1 Analog HD output |
| Senkronizasyon | Internal Synchronization |
| Menu |
| D / N Modu | Auto/Color/BW (Black and White) |
| BLC | Support |
| AGC | High/Medium/Low/Off |
| Function | Brightness, Sharpness, DNR, Mirror, Smart IR |
| General |
| Operating Conditions | -40 °C - 60 °C (-40 °F - 140 °F) |
| Humidity 90% or less (non-condensing) |
| Power Supply | 12 VDC±15% |
| Power Consumption | Max. 4 W |
| IR Range | Up to 20m |
| Boyutlar | 82.6 mm × 69.66 mm (3.38" × 2.74") |
| Ağırlık | 230 g (0.51 lb.) |
