| Camera |
| WDR (Wide Dynamic Range) |
DWDR |
| Image Sensor |
4 MP CMOS image sensor |
| İşaret Sistem |
PAL/NTSC |
| Etkin Piksel |
2560 (H) × 1440 (V) |
| Min. Illumination |
0.01 Lux@(F1.2, AGC ON), 0 Lux with IR |
| Shutter Time |
1/25(1/30) s to 1/50,000 s |
| Lens Mount |
M12 |
| Ayarlama Aralık |
Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360° |
| Day& Night |
IR cut filter |
| Video Frame Rate |
PAL: 1080p@25fps, 4 MP@25fps |
| NTSC: 1080p@30fps, 4 MP@30fps |
| HD Video Çıkışı |
1 Analog HD output |
| Senkronizasyon |
Internal Synchronization |
| Menu |
| D / N Modu |
Auto/Color/BW (Black and White) |
| BLC |
Support |
| AGC |
High/Medium/Low/Off |
| Dil |
English |
| Function |
Brightness, Sharpness, DNR, Mirror, Smart IR |
| General |
| Operating Conditions |
-40 °C - 60 °C (-40 °F - 140 °F) |
| Humidity 90% or less (non-condensing) |
| Power Supply |
12 VDC±15% |
| Power Consumption |
Max. 4 W |
| Weather Proof |
IP66 |
| IR Range |
Up to 40m |
| Boyutlar |
127.92 mm × 102.26 mm (5.04" × 4.03") |
| Ağırlık |
450 g (0.99 lb.) |
