| Camera |
| Image Sensor | 1/2” Progressive Scan CMOS |
| Effective Pixels | 3840(H) x 2160(V) |
| Scanning System | Progressive |
| Min. illumination | Color:0.01Lux@(F1.2,AGC ON) ; |
| B/W:0Lux@(IR LED ON) |
| S/N Ratio | More than 50dB (AGC Closed) |
| IR Range | up to 30m |
| IR On/Off Control | Auto/Manual |
| IR LEDs | 15pcs |
| OSD Joystick | Yes |
| Up the Coax | Yes |
| Pan/Tilt/Rotation Range | Pan:0˚~355˚, Tilt:0˚~80˚, Rotation:0˚~355˚ |
| Lens |
| Lens Type | Motorized |
| Iris | Fixed Iris |
| Focal Length | 3.3~12mm |
| F Number | F1.5 |
| Angle of View | 94°~43° |
| Focus Control | Motorized |
| Close Focus Distance | 0.2m |
| Video |
| Resolution | 8MP (3840×2160) |
| Frame Rate | 15fps |
| Video Output | AHD/TVI/CVI/CVBS |
| Day/Night | Auto / Color / MONO / Ext |
| OSD Menu | Support |
| Wide Dynamic Range | WDR |
| Gain Control | Auto |
| Noise Reduction | 3D DNR, AUTO/MANUAL(1-10) |
| White Balance | Auto |
| BLC | Support |
| Mirror | N/A |
| Motion Detection | N/A |
| Privacy Masking | N/A |
| General |
| Power Supply | DC12V±10% |
| Power Consumption | Max. 4.5W (12V DC, IR ON) |
| Operating Temperature | -10 °C ~ 55 °C (14°F ~ 131 °F) |
| Operating Humidity | Less than 85% RH |
| Ingress Protection | IP66, IK10 |
| Certifications | CE/FCC |
| Casing | Metal |
| Dimensions | Φ130×112mm |
| Net Weight | 667g |
