| Camera |
| Image Sensor |
1/2” Progressive Scan CMOS |
| Effective Pixels |
3840(H) x 2160(V) |
| Scanning System |
Progressive |
| Min. illumination |
Color:0.01Lux@(F1.2,AGC ON) ; |
| B/W:0Lux@(IR LED ON) |
| S/N Ratio |
More than 50dB (AGC Closed) |
| IR Range |
up to 20m |
| IR On/Off Control |
Auto/Manual |
| IR LEDs |
2pcs |
| OSD Joystick |
Yes |
| Up the Coax |
Yes |
| Pan/Tilt/Rotation Range |
Pan:0˚~350˚; Tilt:0˚~75˚; Rotation:0˚~350˚ |
| Lens |
| Lens Type |
Fixed |
| Iris |
Fixed Iris |
| Focal Length |
3.6mm |
| F Number |
F1.6 |
| Angle of View |
H: 80.9°, V: 43° |
| Focus Control |
Fixed |
| Close Focus Distance |
0.5m |
| Video |
| Resolution |
8MP (3840×2160) |
| Frame Rate |
15fps |
| Video Output |
AHD/TVI/CVI/CVBS |
| Day/Night |
Auto / Color / MONO / Ext |
| OSD Menu |
Support |
| Wide Dynamic Range |
WDR |
| Gain Control |
Auto |
| Noise Reduction |
3D DNR, AUTO/MANUAL(1-10) |
| White Balance |
Auto |
| BLC |
Support |
| Mirror |
N/A |
| Motion Detection |
N/A |
| Privacy Masking |
N/A |
| General |
| Power Supply |
DC12V±10% |
| Power Consumption |
Max. 3W (12V DC, IR ON) |
| Operating Temperature |
-10 °C ~ 55 °C (14°F ~ 131 °F) |
| Operating Humidity |
Less than 85% RH |
| Ingress Protection |
IP67, IK10 |
| Certifications |
CE/FCC |
| Casing |
Metal |
| Dimensions |
Φ110×85.4mm |
| Net Weight |
390g |
