Özellikler
- Motorized Auto Focus Zoom lens 3,8 ~ 38 mm
- 0 Lux: Integrated LED IR Illuminator to see even in total darkness
- Concealed Cable Management
- Built-in Service Monitor Port & OSD Control Port
- F-DNR Fog Digital Noise Reduction
- Video Enhancement: BLC, HSBLC, DNR
- Extended Temperature range -25°C ~ +55°C
- Support Dual Power AC24V/DC12V
Teknik Özellikler
- Image Sensor: 1/4" CCD Sony 960H Ex-view HAD II
- Scanning System: PAL, 50Hz, 625L (V), 2:1 Inter Line Transfer
- Pixels - Effective: 976(H) x 582(V)
- Resolution: 650 (H) lines colour, 700 (H) lines b&w
- Col/B&W: Auto, Color, Removable IR-Cut Filter (ICR)
- Sensitivity Colour: 0.9 lux(50IRE)@F1.8 (SensUp=0, AGC Off), 0.00001 lux 15IRE (SensUpx256) F1.8
- Sensitivity B&W: 0 Lux LED IR on
- Shutter Speed: AUTO, OFF, FLK, 1/250, 1/500, 1/1000, 1/2000, 1/5000, 1/10000, 1/20000, 1/50000, 1/100000
- S/N Ratio: >52 dB
- Lens Focal Length: 3.8 ~ 38 mm
- Viewing Angle: 50°(W) ~ 5.5°(T)
- Optical Zoom Ratio: x 10
- Lens Drive Type: Auto iris (DC)
- Iris F-Number: F= 1.8 ~ 360
- IR LED: 35 pcs.
- Optical Wavelength: 850 nm
- Max. IR Distance: 30/45 m (according to scene reflexion)
- Digital Zoom: Off/1 ~ 12x
- Sens Up: Off ~ x256, auto
- Motion Detection: On/ Off/ Sensitivity/ 4 Area setting
- Number of Privacy Zones: 8
- BLC Back Light: BLC, HSBLC, OFF, d-WDR
- Digital Noise Reduction (DNR): OFF/ON/SMART (level 0~255)
- OSD: Yes
- Camera ID: 20 character
- White Balance: ATW, AWB, AWC-SET, MANUAL, INDOOR, OUTDOOR
- Presettings: CUSTOM, SPEED DOME, IR MODE, INDOOR, OUTDOOR, LOW LIGHT,HALL WAY
- Protection Rating: IP66
- Video Outputs: 1 CVBS 1 Vpp (BNC) & 1 test monitor out
- Additional Features: Image: Freeze, Negative
- Accessories included: Multi-Language Manual, Template, Cable for Service Monitor, Screws
- Humidity: less than 90%, non condensing
- Operating Temperature: -25°C ~ +55°C
- Supply Voltage: 12 Vdc / 24 Vac
- Power Consumption: 7.8 (LED on) W
- Weight: 1 kg
- Dimensions w*h*d: Ø 99 x 224 mm
Grundig GCA B2357T Bullet Kamera PDF Dosyası203.72 KB
