Özellikler
- 16 Channel video D1 400fps recording capability
- High Picture Quality: H.264, Full D1(704x576)
- Supports up to 4 monitors that can be configured individually
- Remote monitoring and control through network (LAN)
- Compatible to French law of August 2007 for quality in CCTV applications
- Compatible with many mobile applications such as iPhone, Blackberry, Android and Windows Mobile
Teknik Özellikler
- Operating System: Embedded OS
- Video Inputs: 16 CH Composite, BNC, Looped
- Video Outputs: 4 CVBS (4 Main) incl. 2 DVI (HDMI/VGA compatible)
- Basic Internal Storage: 1 TB
- Max. Storage Capacity: 8 TB, 32TB (GDS-R04A)
- Data Mirroring: Software based
- Video Compression: H.264, JPEG
- Recording Resolution: Full D1 (704x576), Half D1 (704x288), CIF (352x288)
- Recording Speed: 400fps (352x288), 400fps (704x288), 400fps (704x576)
- Recording Mode: Continuous, Event (Alarm, Motion, Video Loss), Schedule, Manual
- Display Resolution: max. 1920 x 1080
- Display Speed: 400 fps
- Auto Switching: 3, 5, 10, 20, 30 sec, Event or manual, Multi Channel Views
- Internal Backup: Built in DVD writer
- External Backup: USB HDD, USB Memory, DVD-R, Network, eSATA
- Watermark: Yes
- Search Mode: Date/Time, Event (Alarm, Motion, Video Loss, Text) Thumbnails
- Motion Detection: On/ Off/ Area Setting
- Event Source: Motion, Alarm, Text, Video Loss, System
- Event Action: Pop-Up, Relay, E-Mail, FTP, Network, Buzzer, PTZ Preset
- Audio Inputs: 16ch: 4 RCA built-in, 12 D-sub (cable optional)
- Audio Outputs: 1 CH, RCA
- Alarm Inputs: 16 contact input N/O or N/C
- Alarm Outputs: 8 (TTL), 2 Relay
- Interfaces: 2 port RS-485, 1 port RS-232, 1 DAS, 1 Ethernet and 2 USB 2.0 ports
- ATM/POS: Supports up to 16 ATM/POS with VSI-Pro Hydra Modules
- Time Setting: Setting by NTP Server local or internet
- Video Streaming: Versatile Triple Streaming (Dual H.264 + single JPEG)
- Multiplex Function: Pentaplex
- Network Interface: Ethernet, 10/100 Base-T for PC client, 1000 Base-T for storage, ADSL Static IP, ADSL Dynamic IP(PPPoE),Cable Network (Dynamic IP)
- Client software: Windows (XP, Vista, 7), Web Viewer: IE, Firefox, Safari, Chrome; Mobile: iPhone, Blackberry, Android, Windows Mobile, Symbian
- Operating Temperature: 5°C ~ +45°C
- Humidity: less than 90%, non condensing
- Supply Voltage: 110 ~ 240 Vac, 50Hz
- Power Consumption: 75 W
- Weight: 9.5 kg
- Dimensions w*h*d: 445 x 88 x 418 mm
Grundig GDV C4416A DVR Kayıt Cihazı PDF Dosyası591.11 KB
