Özellikler
- 16 Channel video 960H Real-Time recording capability
- Aux Monitor with 16-Split View & Spot Monitors with 4-Split View and editable Sequence Function
- 4 independent Spot Monitors
- Tampering Alarm
- Coaxitron support for telemetry and camera setup
- Free DDNS service
- Multiplex (Live/Playback, Recording, Backup, Networking)
- USB, Remote & FTP Backup function
- Remote monitoring and control through network (LAN)
- Easy to use user interface
- Compatible to French law of August 2007 for quality in CCTV applications
- 19″ mountable and rack adapters included
Teknik Özellikler
- Operating System: Embedded Linux
- Video Inputs: 16 CH Composite, BNC, Looped
- Video Outputs: 5 CVBS BNC (1 Main, 4 Spots), 1 HDMI, 1 VGA
- Harddisk bay: 5 x SATA II
- Video Compression: H.264
- Recording Resolution: 960H (960×576), 4CIF (704×576), 2CIF (704 x 288), CIF (352×288)
- Recording Speed: 400fps (352×288), 400fps (704×288), 400fps (704×576), 400fps (960×576)
- Recording Mode: Continuous, Event Alarm, Motion, Video Loss, Schedule, Manual
- Pre-Alarm: Off, 1, 2, 3, 4, 5, 10, 15 sec.
- Post-Alarm: Off, 1, 2, 3, 4, 5, 10, 15, 30, sec., 1, 2, 3 min.
- Display Resolution: max. 1920 x 1080
- Display Speed: 400 fps
- Display Mode: Full screen, 4, 6, 8, 9, 16
- PTZ Control: Pan / Tilt / Zoom / Focus / Preset / Sequence / Auto Pan
- Auto Switching: 0, 3, 5, 10, 20, 30 sec, Event or manual, Multi Channel Views
- External Backup: USB HDD, USB Memory,Network, FTP
- Watermark: Yes
- Privacy zones: 4 per camera
- Search Mode: Date/Time, Event, Thumbnail
- Motion Detection: On/ Off/ Sensitivity/ Area setting
- Event Source: Motion, Alarm, Video Loss, System, Tampering
- Event Action: Pop-Up, Relay, E-Mail, Buzzer, PTZ Preset
- Audio Inputs: 16 CH, 3.5mm Jack socket
- Audio Outputs: 2 CH, 3.5mm Jack socket
- Alarm Inputs: 17 contact input N/O or N/C, 1 contact input for reset
- Alarm Outputs: 16
- Network: 2x 10/100/1000Mbps RJ45 ports
- Serial Interface(s): 1x RS232, 1x RS485, 3x USB, 1x eSATA
- Multiplex Function: Triplex
- Video Streaming: Versatile Dual Streaming
- Time Setting: Setting by NTP Server local or internet
- Client software: Windows (XP, Vista, 7), Web Viewer: IE, Firefox, Safari, Chrome; Mobile: iPhone, Android
- Operating Temperature: 0°C ~ +40°C
- Humidity: less than 90%, non condensing
- Supply Voltage: 110 ~ 240 Vac, 50Hz
- Certification: FCC,CE
- Power Consumption: 24 (without HDD) W
- Weight: 5.5 kg
- Dimensions w*h*d: 430 x 88 x 367 mm
Grundig GRA D4416A DVR Kayıt Cihazı PDF Dosyası166.71 KB
