| Video/Audio Input |
| IP video input: |
16-ch |
| Two-way audio input: |
1-ch, RCA (2.0 Vp-p, 1kΩ) |
| Network |
| Incoming bandwidth: |
160Mbps |
| Outgoing bandwidth: |
80Mbps |
| Remote connection: |
128 |
| Video/Audio Output |
| HDMI/VGA output: |
1-ch, resolution: |
| |
1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, |
| |
1024 × 768 /60Hz |
| Recording Resolution: |
6 MP/5 MP/4 MP/3 MP 1080p/UXGA/720p/ |
| |
VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Frame Rate: |
Main stream: 50 fps (P) / 60 fps (N) |
| |
Sub-stream: 50 fps (P) / 60 fps (N) |
| Audio Output: |
1-ch, RCA (Linear, 1kΩ) |
| Synchronous Playback: |
16-ch |
| Decoding |
| Live view / Playback: |
6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Capability: |
6-ch@1080P |
| Hard Disk |
| SATA: |
1 SATA interface for 1 HDD |
| Capacity: |
Up to 4TB for each disk |
| External Interface |
| Network Interface: |
1RJ-45 10/100/1000Mbps self-adaptive Ethernet interface |
| USB Interface: |
1 × USB 2.0 and 1 × USB 3.0 |
| Alarm In: |
4-ch |
| Alarm Out: |
1-ch |
| POE |
| Interface: |
4 independent 100 Mbps PoE |
| |
network interfaces |
| Max. Power: |
50W |
| Supported Standard: |
AF and AT |
| General |
| Power Supply: |
48V DC |
| Consumption(without hard disk and POE): |
≤ 10W |
| Working Temperature: |
-10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF) |
| Working Humidity: |
10 % ~ 90 % |
| Chassis: |
1U chassis |
| Dimensions: |
315 × 230 × 45mm |
| |
(12.4 ×9.1 × 1.8 inch) |
| Weight(without HDD): |
≤ 1 Kg (2.2 lb) |
