Video/Audio Input |
IP video input: | 16-ch |
Two-way audio input: | 1-ch, RCA (2.0 Vp-p, 1kΩ) |
Network |
Incoming bandwidth: | 160Mbps |
Outgoing bandwidth: | 256Mpbs |
Remote connection: | 128 |
Video/Audio Output |
Recording Resolution: | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
Audio Output: | 1-ch, RCA (Linear, 1kΩ) |
Synchronous Playback: | 16-ch |
VGA Output: | 1-ch, resolution: 1920*1080P/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz |
Decoding |
Live view / Playback: | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
Capability: | 4-ch@8MP,16-ch@1080P |
Hard Disk |
SATA: | 2 SATA interfaces for 2 HDDs |
Capacity: | Up to 6TB capacity for each HDD |
External Interface |
Network Interface: | 1RJ-45 10/100/1000Mbps self-adaptive Ethernet interface |
Serial Interface: | RS-232 |
USB Interface: | Front panel: 1 × USB 2.0 |
| Rear panel: 1 × USB 3.0 |
Alarm In: | 4-ch |
Alarm Out: | 1-ch |
General |
Power Supply: | 100 to 240 VAC, 50 to 60 Hz |
Consumption(without hard disk and POE): | ≤15 W |
Working Temperature: | -10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF) |
Working Humidity: | 10 % ~ 90 % |
Chassis: | 380 chassis |
Dimensions: | 380 × 290 ×45 mm (15.0"× 11.4" × 1.8") |
Weight(without HDD): | ≤ 3 Kg (6.6 lb) |
