| IP video input |
16-ch |
| Two-way audio |
1-ch, BNC (2.0 Vp-p, 1kΩ) |
| Incoming bandwidth |
50Mbps |
| |
100Mbps (when RAID is enabled) |
| Outgoing bandwidth |
240Mbps |
| |
100Mbps (when RAID is enabled) |
| Remote Connection |
128 |
| Recording resolution |
6MP /5MP /3MP /1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF /QCIF |
| CVBS output |
1-ch, BNC (1.0 Vp-p, 75 Ω) |
| |
Resolution: 704 × 576 (PAL); 704 × 480 (NTSC) |
| HDMI output |
1-ch, resolution: |
| |
1920 × 1080P /60Hz, 1920×1080P /50Hz, 1600 × 1200/60Hz, |
| |
1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz |
| VGA output |
1-ch, resolution: |
| |
1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, |
| |
1280 × 720 /60Hz, 1024 × 768 /60Hz |
| Audio output |
2-ch, BNC (Linear, 600Ω) |
| Live view / Playback resolution |
6MP /5MP /3MP /1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF /QCIF |
| Capability |
10-ch@720P, 5-ch@1080P |
| SATA |
8 SATA interfaces for 4 HDDs + 1 DVD-R/W (default), or 8HDDs |
| eSATA |
1 eSATA interface |
| Capacity |
Up to 4TB capacity for each HDD |
| Array type |
RAID0, RAID1, RAID5, RAID10 |
| Number of array |
4 |
| Number of virtual disk |
8 |
| Network interface |
2 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interfaces |
| Serial interface |
RS-232; RS-485; Keyboard; |
| USB interface |
3 × USB 2.0 |
| Alarm in/out |
16.Nis |
| Power supply |
100 ~ 240 VAC, 6.3 A, 50 ~ 60 Hz |
| Consumption |
≤ 40 W |
| Working temperature |
-10 ºC ~ +55 ºC (14ºF ~ 131ºF) |
| Working humidity |
10 % ~ 90 % |
| Chassis |
19-inch rack-mounted 2U chassis |
| Dimensions |
445 × 470 ×90 mm (17.5" ×18.5"× 3.5") |
| Weight |
≤ 8 Kg (17.64 lb) |
