Video/Audio Input |
IP Video Input | 16-ch |
Two-way Audio Input | 1-ch, RCA |
Network |
Incoming Bandwidth | 160Mbps |
Outgoing Bandwidth | 320Mbps |
Remote Users | 128 |
Protocols | P2P, UPnP, NTP, DHCP, PPPoE |
Video/Audio Output |
HDMI/VGA Output | HDMI1/VGA: |
1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
HDMI2: |
4K (3840x2160) /60Hz, 4K (3840x2160) /30Hz, 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
Recording Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
Audio Output | 1-ch, RCA |
Synchronous Playback | 16-ch |
Corridor Mode Screen | 3/4/5/7/9/10/12/16 |
Decoding |
Decoding format | Ultra 265, H.265, H.264 |
Live view/ Playback | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
Capability | 3 x 12MP@25, 4 x 4K@30, 8 x 4MP@30, 16 x 1080p@30, 32 x 960p@25 |
Hard Disk |
SATA | 4 SATA interfaces |
Capacity | up to 8TB for each HDD |
External Interface |
Network Interface | 2 RJ45 10M/100M/1000M self-adaptive Ethernet Interfaces |
Serial Interface | 1 x RS485 |
USB Interface | Front panel: 1 x USB2.0 |
Rear panel: 1 x USB2.0, 1 x USB3.0 |
Alarm In | 16-ch |
Alarm Out | 4-ch |
General |
Power Supply | 12V DC |
Power Consumption: ≤ 12W( without HDD ) |
Working Environment | -10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90% RH(non-condensing) |
Dimensions(W×D×H) | 440mm × 344mm× 44mm (17.3" × 13.5"×1.7" ) |
Weight ( without HDD ) | ≤ 3.14 Kg ( 6.92 lb ) |
