| Video/Audio Input |
| IP video input: |
4-ch |
| Two-way audio input: |
1-ch, RCA (2.0 Vp-p, 1kΩ) |
| Network |
| Incoming bandwidth: |
40Mbps |
| Outgoing bandwidth: |
40Mbps |
| Video/Audio Output |
| HDMI/VGA output: |
1-ch, resolution: |
| |
1920 × 1080P /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz |
| Frame Rate: |
Main stream: 50 fps (P) / 60 fps (N) |
| |
Sub-stream: 50 fps (P) / 60 fps (N) |
| Audio Output: |
1-ch, RCA (Linear, 1kΩ) |
| Decoding |
| Capability: |
4-ch@1080P |
| Hard Disk |
| SATA: |
1 SATA interface for 1 HDD |
| Capacity: |
Up to 6TB capacity for each HDD |
| External Interface |
| Network Interface: |
1 RJ-45 10 / 100 Mbps selfadaptive |
| |
Ethernet interface |
| USB Interface: |
2, USB2.0 |
| General |
| Power Supply: |
12 VDC |
| Consumption(without hard disk and POE): |
≤ 18 W |
| Working Temperature: |
-10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF) |
| Working Humidity: |
10 % ~ 90 % |
| Dimensions: |
200 × 205 × 48 mm (7.9" × 8.1" × 1.9") |
| Weight(without HDD): |
≤ 1 kg (2.2 lb) |
