| Video/Audio Input |
| IP Video Input | 4-ch |
| Two-way Audio Input | 1-ch,RCA |
| Network |
| Incoming Bandwidth | 40Mbps |
| Outgoing Bandwidth | 64Mbps |
| Remote Users | 128 |
| Video/Audio Output |
| HDMI/VGA Output | HDMI/VGA: |
| | 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
| Recording Resolution | 4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Audio Output | 1-ch,RCA |
| Synchronous Playback | 4-ch |
| Decoding |
| Compression | H.264 |
| Live view/Playback | 4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Capability | 2 x 4MP@20, 4 x 1080P@30 |
| Hard Disk |
| SATA | 1 SATA interface |
| Capacity | up to 8TB for each disk |
| External Interface |
| Network Interface | 1 RJ-45 10M/100M Self-adaptive Ethernet Interface |
| USB Interface | Rear panel: 1 x USB2.0, 1 x USB3.0 |
| PoE |
| Interface | 4 independent 100 Mbps PoEnetwork interfaces |
| Supported Standard | IEEE 802.3at |
| General |
| Power Supply | 48 VDC |
| Consumption | ≤8 W |
| Working Temperature | -10°C ~ + 55°C ( +14°F ~ +131°F ) |
| Working Humidity | 10% ~ 90% |
| Dimensions | 205 ×205 × 42mm ( 8.1” × 8.1” × 1.7”) |
| Weight ( without HDD ) | ≤ 0.58 Kg ( 1.27lb ) |
