| Video/Audio Input |
| IP Video Input |
4-ch |
| Two-way Audio Input |
1-ch, RCA |
| Network |
| Incoming Bandwidth |
40Mbps |
| Outgoing Bandwidth |
64Mbps |
| Remote Users |
128 |
| Video/Audio Output |
| HDMI/VGA Output |
HDMI: |
| 4K(3840x2160)/30Hz, 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
| VGA: |
| 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
| Recording Resolution |
8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Audio Output |
1-ch, RCA |
| Synchronous Playback |
4-ch |
| Decoding |
| Compression |
H.265/H.264 |
| Live view/Playback |
8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Capability |
1 x 4K@30, 2 x 4MP@30, 4 x 1080p@30, 8 x 720p@30, 16 x D1 |
| Hard Disk |
| SATA |
1 SATA interface |
| Capacity |
up to 8TB for each disk |
| External Interface |
| Network Interface |
1 RJ-45 10M/100M Self-adaptive Ethernet Interface |
| USB Interface |
Rear panel: 2 x USB2.0, Front panel: 1 x USB2.0 |
| Alarm In |
4-ch |
| Alarm Out |
1-ch |
| General |
| Power Supply |
12V DC |
| Consumption |
≤ 8 W |
| Working Temperature |
-10°C ~ + 55°C ( +14°F ~ +131°F ) |
| Working Humidity |
10% ~ 90% |
| Dimensions |
44 × 260 × 240mm ( 1.7" × 10.2" × 9.4" ) |
| Weight ( without HDD ) |
≤ 1.12 Kg ( 2.47 lb ) |
