| Camera |
| Image Sensor | 5 MP CMOS |
| Max. Resolution | 2880 (H) × 1620 (V) |
| Scanning System | Progressive |
| Electronic Shutter Speed | PAL: 1/3 s–1/100000 s |
| NTSC: 1/4 s–1/100000 s |
| Min. Illumination | 0.01 lux@F1.6 (Color, 30 IRE) |
| 0.001 lux@F1.6 (B/W, 30 IRE) |
| 0 lux (Illuminator on) |
| S/N Ratio | >65 dB |
| Illumination Distance | 60 m (196.85 ft) |
| Illuminator On/Off Control | Auto/Manual |
| Illuminator Number | 3 (IR light) |
| Pan/Tilt/Rotation Range | Pan: 0°–355° |
| Tilt: 0°–80° |
| Rotation: 0°–355° |
| Lens |
| Lens Type | Motorized Vari-focal |
| Auto Focus | Yes |
| Lens Mount | φ14 |
| Focal Length | 2.7 mm–13.5 mm |
| Max. Aperture | F1.6 |
| Field of View | H: 113°–31.4°; V: 58°–17.6°; D: 138°–36° |
| Iris Control | Fixed |
| Close Focus Distance | 0.8 m (2.62 ft) |
| DORI Distance | Lens | Detect | Observe | Recognize | Identify |
| W | 64.0 m (209.97 ft) | 25.6 m | 12.8 m | 6.4 m |
| (83.99 ft) | (41.99 ft) | (21.00 ft) |
| T | 210.0 m (688.97 ft) | 84.0 m (275.59 ft) | 42.0 m | 21.0 m |
| (137.80 ft) | (68.89 ft) |
| Video |
| Video Frame Rate | CVI: |
| PAL: 5M@25 fps; 4M@25 fps; |
| NTSC: 5M@25 fps; 4M@30 fps; |
| AHD: |
| PAL: 4M@25 fps; |
| NTSC: 4M@30 fps |
| TVI: |
| PAL: 4M@25 fps; |
| NTSC: 4M@30 fps |
| CVBS: |
| PAL: 960H; |
| NTSC: 960H |
| Resolution | 5M (2880 × 1620); 4M (2560 × 1440); 960H (960 × 576/960 × 480) |
| Day/Night | Auto(ICR)/Color/B/W |
| BLC | BLC; HLC; WDR; HLC-Pro |
| WDR | 120 dB |
| White Balance | Auto; Area white balance |
| Gain Control | Auto/Manual |
| Noise Reduction | 3D NR |
| Illumination Mode | Smart IR |
| Defog | Electronic defog |
| Digital Zoom | 4× |
| Mirror | Yes |
| Privacy Masking | Off/On (8 areas, rectangle) |
| Certification |
| Certifications | CE-LVD: EN 62368-1; |
| CE-EMC: EN 55032; EN 55035; |
| FCC: 47 CFR FCC Part 15, Subpart B; |
| UL: UL62368-1 + CAN/CSA C22.2 No. 62368-1-14 |
| Port |
| Video Output | Video output choices of CVI/TVI/AHD/CVBS by one BNC port |
| Audio Input | One channel built-in MIC |
| Power |
| Power Supply | POC (only CVI)/12 VDC ± 30% |
| Power Consumption | Max 7.6 W (12 VDC, IR on) PoC (AT) |
| Environment |
| Operating Temperature | –30 °C to +60 °C (–22 °F to +140 °F) |
| Operating Humidity | <95% (RH), non-condensing |
| Storage Temperature | –30 °C to +60 °C (–22 °F to +140 °F) |
| Storage Humidity | <95% (RH), non-condensing |
| Protection | IK10; IP67 |
| Structure |
| Casing Material | Metal |
| Product Dimensions | Φ126.0 mm × 100.0 mm (Φ4.96" × 3.94") |
| Net Weight | 0.66 kg (1.46 lb) |
| Gross Weight | 0.83 kg (1.83 lb) |
| Installation | Wall mount; ceiling mount; vertical pole mount |
