Dahua HAC-HDW2501TLM-A-POC HDCVI Eyeball Kamera

Özellikler

The parameters and datasheets below can only be applied to2501-S2 series.
In order to use the 5MP 16:9 HDCVI camera, the firmware of XVR must be upgraded to V4.001.0000001.0.R.200908 or later version.
Max 25 fps@5MP (16:9 video output)
Starlight, 120 dB true WDR, 3D NR
CVI/CVBS/AHD/TVI switchable
3.6 mm fixed lens (2.8 mm optional)
Built-in mic
Max. IR length 30 m, Smart IR
IP67, POC (only CVI)/12V±30% DC

Teknik Özellikler

Camera
Image Sensor	5MP CMOS
Max. Resolution	2880 (H) × 1620 (V)
Pixel	5MP
Scanning System	Progressive
Electronic Shutter Speed	PAL: 1/3 s–1/100,000 s
	NTSC: 1/4 s–1/100,000 s
S/N Ratio	＞65dB
Min. Illumination	0.001 Lux/F1.6, 30IRE, 0Lux IR on
Illumination Distance	30 m (98.4 ft)
Illuminator On/Off Control	Auto; manual
Illuminator Number	1 (IR light)
Pan/Tilt/Rotation Range	Pan: 0°–360°
	Tilt: 0°–78°
	Rotation: 0°–360°
Lens
Lens Type	Fixed lens
Mount Type	M12
Focal Length	2.8 mm; 3.6 mm;
Max. Aperture	F1.6
Field of View	2.8 mm:H:111° V:58° D:132°
	3.6 mm: H:92° V:48° D:109°
Iris Type	Fixed
Close Focus Distance	2.8 mm: 0.9 m (3.0 ft)
	3.6 mm: 1.6 m (5.2 ft)
DORI Distance	Lens	Detect	Observe	Recognize	Identify
	2.8 mm	63.6 m (208.7 ft)	25.4 m (83.3 ft)	12.7 m (41.7 ft)	6.4 m(21.0 ft)
	3.6 mm	80.0 m (262.5 ft)	32.0 m(105.0 ft)	16.0 m(52.5 ft)	8.0 m(26.2 ft)
Video
Video Frame Rate	CVI:
	PAL: 5M@25 fps; 4M@25 fps; 1080P@25 fps;
	NTSC: 5M@25 fps; 4M@30 fps; 1080P@30 fps
	AHD:
	PAL: 4M@25 fps;
	NTSC: 4M@30 fps
	TVI:
	PAL: 4M@25 fps;
	NTSC: 4M@30 fps
	CVBS:
	PAL: 960H;
	NTSC: 960H
Resolution	5M (2880 × 1620);
	4M (2560 × 1440);
	1080P (1920 ×1080);
	960 H (960 × 576/960 × 480)
Day/Night	Auto switch by ICR
BLC	BLC/HLC/WDR/HLC-Pro
WDR	120dB
White Balance	Auto; Area WB
Gain Control	Auto/Manual
Noise Reduction	3D NR
Smart Illumination	Yes
Defog	Electronic defog
Digital Zoom	4×
Mirror	Off/On
Privacy Masking	Off/On (8area,rectangle)
Pick-up Distance	5 m (16.4 ft)
Port
Video Output	Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Audio Input	One channel built-in mic
Power
Power Supply	POC (only CVI)/12V±30% DC
Power Consumption	Max 4.3W (12V DC, IR on); PoC (AF)
Environment
Operating Temperature	–40°C to +60°C (-40°F to 140°F); <95% (non-condensation)
Storage Temperature	–40°C to +60°C (-40°F to 140°F); <95% (non-condensation)
Protection Grade	IP67
Structure
Casing	Metal throughout the whole casing
Camera Dimensions	φ94.0 mm × 85.7 mm (φ3.70" × 3.37")
Net Weight	0.33 kg (0.73 lb)
Gross Weight	0.47 kg (1.04 lb)
