Dahua HAC-HFW2802TU-Z-A HDCVI Bullet Kamera

Özellikler

The parameters and datasheets below can only be applied to 2802-S2 series.
Max. 15 fps@4K.
Starlight, 120 dB true WDR, 3D NR.
Smart IR Illumination.
80 m illumination distance.
Super Adapt.
Built-in MIC.
Auto focus, 2.7 mm–13.5 mm motorized lens.
CVI/CVBS/AHD/TVI switchable.
IP67, 12 VDC.

Teknik Özellikler

Camera
4K COMS	4K CMOS
Max. Resolution	3840 (H) × 2160 (V)
Scanning System	Progressive
Electronic Shutter Speed	PAL: 1/3 s–1/100000 s
	NTSC: 1/4 s–1/100000 s
Min. Illumination	0.001 lux@F1.5 (Color, 30 IRE)
	0.0001 lux@F1.5 (B/W, 30 IRE)
	0 lux (Illuminator on)
S/N Ratio	>65dB
Illumination Distance	60 m (196.85 ft)
Illuminator On/Off Control	Auto
Illuminator Number	3 (IR light)
Pan/Tilt/Rotation Range	Pan; 0°–355°
	Tilt: 0°–80°
	Rotation: 0°–355°
Lens
Lens Type	Motorized Vari-focal
Auto Focus	Yes
Lens Mount	φ14
Focal Length	2.7 mm–13.5 mm
Max. Aperture	F1.5
Field of View	H: 113°–47°; V: 60°–26°; D: 133°–53°
Iris Control	Fixed
Close Focus Distance	1.2 m (3.94 ft)
DORI Distance	Lens	Detect	Observe	Recognize	Identify
	2.7 mm	83.4 m	33.4 m	16.7 m	8.3 m
		(273.62 ft)	(109.58 ft)	(54.79 ft)	(27.23 ft)
	13.5 mm	189.6 m	75.8 m	37.9 m	19.0 m
		(622.05 ft)	(248.69 ft)	(124.34 ft)	(62.34 ft)
Video
Video Frame Rate	CVI: PAL: 4K@15 fps; 5M@25 fps; 4M@25 fps;
	NTSC: 4K@15 fps; 5M@25 fps; 4M@30 fps
	AHD: PAL: 4K@15 fps; NTSC: 4K@15 fps
	TVI: PAL: 4K@15 fps; NTSC: 4K@15 fps
	CVBS: PAL: 960H; NTSC: 960H
Resolution	4K (3840 × 2160); 5M (2880 × 1620); 4M (2560 × 1440); 960H (960 × 576/960 × 480)
Day/Night	Auto(ICR)/Color/B/W
BLC	BLC; HLC; WDR; HLC-Pro
WDR	120 dB
White Balance	Auto; Area white balance
Gain Control	Auto/Manual
Noise Reduction	3D NR
Illumination Mode	Smart IR
Defog	Electronic defog
Digital Zoom	4×
Mirror	Yes
Privacy Masking	Off/On (8 areas, rectangle)
Certification
Certifications	CE-LVD: EN 62368-1;
	CE-EMC: EN 55032; EN 55035;
	FCC: 47 CFR FCC Part 15, Subpart B;
	UL: UL62368-1 + CAN/CSA C22.2 No. 62368-1-14
Port
Video Output	Video output choices of CVI/TVI/AHD/CVBS by one BNC port (DIP Switch)
Audio Input	One channel built-in MIC
Power
Power Supply	12 VDC ± 30% (It is recommended to use a power adapter to supply the power for one camera)
Power Consumption	Max 7.8 W (12 VDC, IR on)
Environment
Operating Temperature	–30 °C to +60 °C (–22 °F to +140 °F)
Operating Humidity	<95% (RH), non-condensing
Storage Temperature	–30 °C to +60 °C (–22 °F to +140 °F)
Storage Humidity	<95% (RH), non-condensing
Protection	IP67; IK10
Structure
Casing Material	Metal
Product Dimensions	φ126 mm × 100 mm (φ4.96" × 3.94")
Net Weight	0.64 kg (1.41 lb)
Gross Weight	0.83 Kg (1.83 lb)
Installation	Wall mount; ceiling mount; vertiCamera
Image Sensor	4K CMOS
Max. Resolution	3840 (H) × 2160 (V)
Scanning System	Progressive
Electronic Shutter Speed	PAL: 1/3 s–1/100000 s
	NTSC: 1/4 s–1/100000 s
Min. Illumination	0.001 lux@F1.5 (Color, 30 IRE)
	0.0001 lux@F1.5 (B/W, 30 IRE)
	0 lux (Illuminator on)
S/N Ratio	>65dB
Illumination Distance	80 m (262.47 ft)
Illuminator On/Off Control	Auto
Illuminator Number	4 (IR light)
Pan/Tilt/Rotation Range	Pan: 0°–360°
	Tilt: 0°–90°
	Rotation: 0°–360°
Lens
Lens Type	Motorized Vari-focal
Auto Focus	Yes
Lens Mount	φ14
Focal Length	2.7 mm–13.5 mm
Max. Aperture	F1.5
Field of View	H: 113°–47°; V: 60°–26°; D: 133°–53°
Iris Control	Fixed
Close Focus Distance	1.2 m (3.94 ft)
DORI Distance	Lens	Detect	Observe	Recognize	Identify
	2.7 mm	83.4 m	33.4 m	16.7 m	8.3 m
		(273.62 ft)	(109.58 ft)	(54.79 ft)	(27.23 ft)
	13.5 mm	189.6 m	75.8 m	37.9 m	19.0 m
		(622.05 ft)	(248.69 ft)	(124.34 ft)	(62.34 ft)
Video
Video Frame Rate	CVI: PAL: 4K@15 fps; 5M@25 fps; 4M@25 fps
	NTSC: 4K@15 fps; 5M@25 fps; 4M@30 fps
	AHD: PAL: 4K@15 fps; NTSC: 4K@15 fps
	TVI: PAL: 4K@15 fps; NTSC: 4K@15 fps
	CVBS: PAL: 960H; NTSC: 960H
Resolution	4K (3840 × 2160); 5M (2880 × 1620); 4M (2560 × 1440); 960H (960 × 576/960 × 480)
Day/Night	Auto(ICR)/Color/B/W
BLC	BLC; HLC; WDR; HLC-Pro
WDR	120 dB
White Balance	Auto; Area white balance
Gain Control	Auto/Manual
Noise Reduction	3D NR
Illumination Mode	Smart IR
Defog	Electronic defog
Digital Zoom	4×
Mirror	Yes
Privacy Masking	Off/On (8 areas, rectangle)
Certification
Certifications	CE-LVD: EN 62368-1;
	CE-EMC: EN 55032; EN 55035;
	FCC: 47 CFR FCC Part 15, Subpart B;
	UL: UL62368-1 + CAN/CSA C22.2 No. 62368-1-14
Port
Video Output	Video output choices of CVI/TVI/AHD/CVBS by one BNC port (DIP Switch)
Audio Input	One channel built-in MIC
Power
Power Supply	12 VDC ± 30% (It is recommended to use a power adapter to supply the power for one camera)
Power Consumption	Max 10.9 W (12 VDC, IR on)
Environment
Operating Temperature	–30 °C to +60 °C (–22 °F to +140 °F)
Operating Humidity	<95% (RH), non-condensing
Storage Temperature	–30 °C to +60 °C (–22 °F to +140 °F)
Storage Humidity	<95% (RH), non-condensing
Protection	IP67
Structure
Casing Material	Metal
Product Dimensions	244.1 mm × 90.4 mm × 90.4 mm (9.61" × 3.56" × 3.56")
Net Weight	0.79 kg (1.74 lb)
Gross Weight	1.1 kg (2.43 lb)
Installation	Wall mount; ceiling mount; vertical pole mount
