ONV ONV-POE33010PFM PoE Switch
Özellikler
Teknik Özellikler
| Model | ONV-POE33010PFM |
| Interface Characteristics | |
| Fixed Port | 8*10/100/1000Base-T PoE ports (Data/Power) |
| 2*100/1000Base-X uplink SFP slot ports (Data) | |
| 1 * RS232 console port(115200,N,8,1) | |
| Ethernet Port | 10/100/1000Base-T(X), auto-sensing, full/half duplex MDI/MDI-X self-adaption |
| Twisted Pair Transmission | 10BASE-T: Cat3,4,5 UTP(≤100 meter) |
| 100BASE-TX: Cat5 or later UTP(≤100 meter) | |
| 1000BASE-T: Cat5e or later UTP(≤100 meter) | |
| SFP Slot Port | Gigabit SFP optical fiber interface, default matching optical modules (optional order single-mode / multi-mode, single fiber / dual fiber optical module. LC) |
| Optical Cable/ Distance | Multi mode: 850nm / 0 ~ 500M, single mode: 1310nm/ 0 ~ 40KM, 1550nm /0 ~ 120KM. |
| Chip Parameter | |
| Network Management Type | L2+ |
| Network Protocol | IEEE802.3 10BASE-T, IEEE802.3i 10Base-T |
| IEEE802.3u 100Base-TX, IEEE802.3ab 1000Base-T | |
| IEEE802.3z 1000Base-X, IEEE802.3x | |
| Forwarding Mode | Store and Forward(Full Wire Speed) |
| Switching Capacity | 128Gbps |
|
Forwarding
Rate@64byte
|
14.88Mpps |
| MAC | 8K |
| Buffer Memory | 4.1M |
| Jumbo Frame | 10K |
| CPU(Hz) | 500M |
| DRAM | 1G |
| Flash | 128M |
| LED Indicator | Power:PWR (yellow), system :SYS (green), network ;Link (yellow), POE: PoE (green), Fiber port: L/A(green) |
| Reset Switch | Yes, One-button factory reset |
| PoE & Power | |
| PoE Port | Port 1 to 8 IEEE802.3af/at @ POE |
| PoE Management | Total power limit of PoE power supply |
| PoE output power allocation, off& af &at | |
| PoE output priority configuration | |
| PoE working status | |
| Delay start of power supply | |
| Scheduling of PoE operation and time | |
| Power Supply Pin | Default 1/2 (+), 3/6 (-) |
| Max Power Per Port | 30W; IEEE802.3af/at |
| Total PWR / Input Voltage | 130W (AC100-240V) |
| Power Consumption | Standby:<8W, Full load:<120W |
| Power Supply | Built-in power supply, AC 100~240V 50-60Hz 2.3A |
| Physical Parameter | |
| Operation TEMP / Humidity | -20~+55°C;5%~90% RH Non condensing |
| Storage TEMP / Humidity | -40~+75°C;5%~95% RH Non condensing |
| Dimension (L*W*H) | 270*181*44.5mm |
| Net /Gross Weight | <1.7kg / <2.2kg |
| Installation | Desktop, Wall-mounted, 19 inch 1U cabinet |
| Certification & Warranty | |
| Lightning protection / protection level | Lightning protection: 4KV 8/20us; Protection level: IP30 |
| Certification | CCC;CE mark, commercial; CE/LVD EN60950;FCC Part 15 Class B; RoHS |
| Warranty | 3 years, lifelong maintenance. |
| Network Management Features | |
| Interface | IEEE802.3X (Full-duplex) |
| Broadcast storm control based on port speed | |
| Port real-time traffic management (Flow Interval) | |
| The speed limit of the message flow in the access port. The minimum particle size is 1Gbps. | |
| Layer 3 Features | L2+ Network management, IPV4 management |
| Static route, Default route @ 128 pcs, APR @ 1024 pcs | |
| VLAN | VLAN based on the protocol |
| 4K VLAN based on port, IEEE802.1q | |
| Port configuration of Access, Trunk, Hybrid | |
| Port Aggregation | LACP, Static aggregation |
| Max 5 aggregation groups and 8 ports per group. | |
| Spanning Tree | STP (IEEE802.1d), RSTP (IEEE802.1w), MSTP (IEEE802.1s) |
| Multicast | IGMP Snooping v1/v2, Max 1024 multicast groups, Fast log out |
| Multicast VLAN | |
| Port Mirroring | Bidirectional data mirroring based on port |
| QoS | Flow-based redirection |
| Flow-based rate limiting | |
| Flow-based packet filtering | |
| 8*Output queues of each port | |
| 802.1p/DSCP priority mapping | |
| Diff-Serv QoS,Priority Mark/Remark | |
| Queue Scheduling Algorithm (SP, WRR, SP+WRR) | |
| ACL | Port-based Issuing ACL |
| ACL based on port and VLAN | |
| L2 to L4 packet filtering, matching first 80 bytes message. Provide ACL based on MAC, Destination MAC address, IP Source, Destination IP, IP Protocol Type, TCP/UDP Port, TCP/UDP Port Range, and VLAN, etc. | |
| Security | IP-MAC-VLAN-Port binding |
| ARP inspection,Anti-DoS attack | |
| AAA & RADIUS,MAC learning limit | |
| Mac black holes,IP source protection | |
| Broadcast storm control,Backup for host datum | |
| SSH 2.0,SSL,Port isolation,ARP message speed limit | |
| User hierarchical management and password protection | |
| DHCP | DHCP Client,DHCP Snooping,DHCP Server |
| Management | One-key recovery |
| Cable Diagnose,LLDP | |
| Web Management (HTTPS) | |
| NTP,System work log,Ping Test | |
| CPU instant utilization status view | |
| Console/AUX Modem/Telnet/SSH2.0 CLI | |
| ONV-NMS - Smart Network Management System Platform (LLDP+SNMP) | |
| Download & Management on FTP, TFTP, Xmodem, SFTP,SNMP V1/V2C/V3 | |
| System | Category 5 Ethernet network cable |
| Web browser: Mozilla Firefox 2.5 or higher, Google browser chrome V42 or higher, Microsoft Internet Explorer10 or later; | |
| TCP/IP, network adapter, and network operating system (such as Microsoft Windows, Linux, or Mac OS X) installed on each computer in a network | |
