ONV ONV-POE33108PF PoE Switch

Özellikler

Unmanaged PoE fiber switch with 8*10/100/1000M RJ45 ports and 2*1000M uplink SFP fiber slot ports, port 1-8 can support IEEE802.3af/at PoE standard.
Support 1U/19 inch rack installation.

Teknik Özellikler

Model	ONV-POE33108PF
Interface Characteristics
Fixed Port	8*10/100/1000Base-T PoE ports (Data /Power)
Fixed Port	2*1000Base-X uplink SFP ports (Data)
Ethernet Port	Port 1-8 can support 10/100/1000Base-T,auto-sensing, full/half duplex MDI/MDI-X
Twisted Pair Transmission	10BASE-T: Cat3,4,5 UTP(≤100 meter)
	100BASE-TX: Cat5 or later UTP(≤100 meter)
	1000BASE-T: Cat5e or later UTP(≤100 meter)
SFP Slot Port	Gigabit SFP optical fiber interface, default matching optical modules (optional order single-mode / multi-mode, single fiber / dual fiber optical module. LC)
Optical Cable	Multi-mode: 850nm 0 ~ 550M,single mode: 1310nm 0 ~ 40KM, 1550nm 0 ~ 120KM.
Chip Parameter
Network Protocol	IEEE802.3 10BASE-T, IEEE802.3i 10Base-T
	IEEE802.3u 100Base-TX, IEEE802.3ab 1000Base-T
	IEEE802.3z 1000Base-X, IEEE802.3x
Forwarding Mode	Store and Forward(Full Wire Speed)
Switching Capacity	20Gbps (Non-blocking)
Forwarding Rate@64byte	14.88Mpps
MAC	8K
Buffer Memory	4M
Jumbo Frame	9.6K
LED Indicator	Power: PWR (green), network :Link (yellow), PoE: PoE(green), fiber port :L/A (green)
PoE & Power Supply
PoE Port	Port 1 to 8 IEEE802.3af/at @ POE
Power Supply Pin	Default 1/2 (+), 3/6 (-), optional 4/5 (+), 7/8 (-)
Max Power Per Port	30W; IEEE802.3af/at
Total PWR / Input Voltage	130W (AC100-240V)
Power Consumption	Standby<6W,Full load<120W
Power Supply	External power adapter,
Power Supply	AC100~240V 50-60Hz 2.3A
Physical Parameter
Operation TEMP / Humidity	-20~+55°C;5%~90% RH Non condensing
Storage TEMP / Humidity	-40~+75°C;5%~95% RH Non condensing
Dimension (LWH)	27018144.5mm
Net /Gross Weight	<1.3kg / <1.8kg
Installation	Desktop, wall mounted,19 inch 1U cabinet
Certification & Warranty
Lightning protection / protection level	Lightning protection: 4KV 8/20us; Protection level: IP30
Certification	CCC;CE mark, commercial; CE/LVD EN60950;FCC Part 15 Class B; RoHS
Warranty	3 years, lifelong maintenance.
