| Ports |
| 10/100M RJ45 |
16 |
| 10/100/1000M RJ45 |
2 |
| 1000M SFP |
2 (multiplex) |
| Port of high priority |
Port 1 to 8 |
| Performance |
| Store-and-forward |
Support |
| MAC address table |
4K |
| MAC address learning |
Automatic learning/Aging |
| Backplane bandwidth |
7.2 Gbps |
| Power Over Ethernet |
| PoE Standard |
IEEE 802.3af, IEEE802.3at |
| PoE cable core |
Supports 8-core power supply and simultaneous power supply via the 1236 and 4578 line order. |
| PoE port |
Port 1 to 16 |
| Port max. power |
30W |
| Switch max. power |
230W |
| General |
| Power Supply |
100 to 240 VAC, 50/60Hz |
| Working Temperature |
0 oC to +40 oC (+32 oF to +104 oF) |
| Working Humidity |
10% to 90% (Relative humidity, without condensation) |
| Storage Temperature |
-40 oC to +70 oC (-40 oF to +158 oF) |
| Storage Humidity |
5% to 90% (Relative humidity, without condensation) |
| Lighting Protection Grade |
| For port |
4 KV |
| For power supply |
6 KV |
| Data Transfer Rate |
| Ethernet |
10 Mbps (half-duplex)/20 Mbps (full-duplex) |
| Fast Ethernet: |
100 Mbps (half-duplex)/200 Mbps (full-duplex) |
| Gigabit Ethernet |
2000 Mbps (full-duplex) |
| Network Media |
| Ethernet |
UTP/STP of CAT3 or above |
| Fast Ethernet |
UTP/STP of CAT5 or above |
| Gigabit Ethernet |
Recommended UTP/STP of CAT5e or CAT6 |
| 1000 Base-SX |
MMF (Multi-Mode Fiber) |
| 1000 Base-LX |
MMF (Multi-Mode Fiber) or SMF (Single Mode Fiber) |
| Parameters |
| Network Standard |
IEEE 802.3, IEEE 802.3u, IEEE802.3ab, IEEE 802.3af, IEEE802.3at, IEEE 802.3x, IEEE802.3z |
| Port |
When the EXTEND mode is enabled, the maximum data transmission (for 10 Mbps full/half duplex communication only) and power supply distance can be extended to 250 meters via CAT5e twisted pair or above |
| PoE |
IEEE 802.3at/IEEE 802.3af |
| Enable/Disable PoE |
| PoE over-temperature protection |
| Display power supply status and output power of the PoE port |
| Dynamic power supply of the PoE port. Power supply priority (Port 1 > Port 2 > … > Port 16… > Port 24) |
| Security Feature |
MAC address binding |
| VLAN |
One-key enable VLAN |
| Port VLAN (Max. 18/26 groups can be configured) |
| IEEE 802.1Q VLAN (Max. 31 groups can be configured) |
| Port Trunk |
3 groups: |
| Port 1, 2, 3 and 4 |
| Port 5, 6, 7 and 8 |
| Port G1/G1-F and G2/G2-F |
| STP (Spanning Tree) |
IEEE 802.1d Spanning Tree Protocol |
| IEEE 802.1w RSTP (Rapid Spanning Tree Protocol) |
| Multicast |
IGMP Snooping and IGMP v1/v2 |
| Mirroring |
N: 1 port mirroring |
| QoS |
FIFO (First-in First-out) |
| SP (Strict Priority) |
| WP (Weighted Priority) |
| MAC Address Management |
MAC address aging and static MAC address configuration |
| Loading and Upgrade |
HTTP upgrade |
| Import/Export configuration file |
| Management and Maintenance |
SNMP v1/v2 |
| WEB management |
