Planet FGSD-1821P Fast Ethernet PoE Switch
Teknik Özellikler
| Hardware Specifications | |
| Fast Ethernet Copper Ports | 16 x 10/100BASE-TX RJ45 auto-MDI/MDI-X ports |
| Gigabit Ethernet Copper Ports | 2 x 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports |
| (Port-17 shared with SFP port) | |
| SFP Ports | 1 x 1000BASE-SX/LX/BX SFP interface (shared with Port-17) |
| DIP Switch | Selectable operation mode |
| - Standard | |
| - VLAN | |
| - Extend | |
| Dimensions (W x D x H) | 280 x 180 x 44 mm (1U height) |
| Enclosure | Metal |
| Weight | 1800g |
| Power Requirements | 100~240V AC, 50/60Hz, 5A max. |
| Power Consumption/Dissipation | Max. 207 watts/706 BTU |
| Thermal Fan | 1 |
| ESD Protection | Contact discharge of ±6KV DC, |
| Air discharge of ±8KV DC | |
| Surge Protection | Differential Mode ±4KV, Common Mode ±6KV |
| Installation | Desktop or rack-mount installation |
| LED Indicators | System |
| Power (Green) | |
| PoE Max. (Green) | |
| 10/100/1000T RJ45 Interfaces | |
| 10/100/1000 LNK / ACT (Green) | |
| PoE-in-Use (Amber) | |
| 1000X SFP Interfaces | |
| 1000 LNK / ACT (Green) | |
| Switching | |
| Switch Architecture | Store-and-Forward |
| Switch Fabric | 7.2Gbps/non-blocking |
| Switch Throughput@64bytes | 5.36Mpps |
| MAC Address Table | 16K entries |
| Jumbo Frame | 16K bytes |
| Flow Control | IEEE 802.3x pause frame for full duplex; back pressure for half duplex |
| Power over Ethernet | |
| PoE Standard | IEEE 802.3at Power over Ethernet Plus/PSE |
| PoE Injector Ports | 16 |
| PoE Power Supply Type | End-span: 1/2 (+), 3/6 (-) |
| PoE Power Output | Per port 55V DC, 600mA. max. 32 watts |
| PoE Power Budget | 185 watts |
| Number of PDs, 7 watts | 16 |
| Number of PDs, 15.4 watts | 12 |
| Number of PDs, 30 watts | 6 |
| Standards Conformance | |
| Regulatory Compliance | FCC Part 15 Class A, CE |
| Standards Compliance | IEEE 802.3 10BASE-T |
| IEEE 802.3u 100BASE-TX | |
| IEEE 802.3ab Gigabit 1000BASE-T | |
| IEEE 802.3z Gigabit SX/LX | |
| IEEE 802.3x flow control and back pressure | |
| IEEE 802.3af Power over Ethernet | |
| IEEE 802.3at Power over Ethernet Plus | |
| IEEE 802.3az Energy-Efficient Ethernet | |
| Environment | |
| Operating | Temperature: 0 ~ 50 degrees C |
| Relative Humidity: 5~ 95% (non-condensing) | |
| Storage | Temperature: -10 ~ 70 degrees C |
| Relative Humidity: 5 ~ 95% (non-condensing) | |
Planet FGSD-1821P Fast Ethernet PoE Switch Pdf Dosyası2.91 MB
Teknik Kısa
PoE : PoE Plus
Port Hızı : 100 Mbps
Yönetilebilirlik : Yönetilemez
Aktarım Port Sayısı : 2
Aktarım Türü : Gbit Fiber
Montaj Tipi : Desk Mount
PoE Port Sayısı :
16 Port
16 Port PoE Güç Bütçesi : 130-200 Watt
