| Technical Specification |
| Ethernet Port |
2*10/100/1000 Base-T (Combo port) |
| 2*1000 Base-X (Combo port) |
| 24*10/100 Base-T (PoE power supply) |
| PoE Power Consumption |
Port1/2 support Hi-PoE (60W), PoE+, PoE |
| Each power ≤30W |
| Total≤360W |
| PoE Protocol |
IEEE802.3af, IEEE802.3at, Hi-PoE |
| Switching Capacity |
8.8G |
| Packet Forwarding Rate |
6.55Mpps |
| Humidity |
10%~90% |
| Power |
AC 100~240V |
| Lightning Protection |
Common Mode 4KV |
| Differential Mode 2KV |
| Working Temperature |
﹣10℃~55℃ |
| Weight |
3.51kg |
| Dimension(W×D×H) |
440mm x300mm x44mm |
| Accessories Model |
| SF3950 |
1.25G 850nm,500m,LC, Multi-mode |
| SF3960 |
1.25G 1310/1550nm,20km,LC, Single-mode |
| SF3970 |
1.25G 1550/1310nm,20km,LC, Single-mode |
| Service Characteristics |
| System |
Username / password: admin/admin |
| IP Address :192.168.1.110/24 |
| PoE Budget |
360W |
| MAC Table |
4K |
| VLAN |
802.1Q Standard VLAN |
| Spanning Tree |
STP |
| RSTP |
| Port Aggregation |
Static link aggregation |
| LACP protocol |
| Mirroring |
Many-to-one port mirroring |
| DHCP |
Support DHCP-Client |
| Long Distance Mode |
"Power & Data" transmission distance up to 250m |
| Flow Control |
Half-duplex based on back pressure type control; |
| Full duplex based on PAUSE frame |
| Security Features |
IP+MAC binding based on port; |
| IEEE802.1x port authentication |
| System Maintenance |
One-key recovery |
| Support the updated packet upload |
| System log |
| QoS |
High and low priority, WRR |
| 802.1P, DSCP |
| Support priority according to protocol |
| Network Management |
WEB(http and https protocol) |
| Support SNMP V1/V2C/V3 |
| PoE Management |
PoE setting (real-time port comsumption) |
| PoE event statistics |
| Green PoE |
