Planet WGSW 24040HP 10/100/1000 PoE Switch
Teknik Özellikler
| Hardware Specifications | |
| Hardware Version | 2 |
| Copper Ports | 24 10/ 100/1000BASE-T RJ45 auto-MDI/MDI-X ports |
| 10/100/1000Mbps / SFP Combo Interfaces | 4 10/100/1000Mbps TP and SFP shared combo interfaces, SFP (Mini-GBIC) supports 100/1000Mbps Dual mode DDM, shared with Port-21 to Port-24 |
| Console | 1 x RJ45 serial port (115200, 8, N, 1) |
| Switch Architecture | Store-and-Forward |
| Switch Fabric | 48Gbps / non-blocking |
| Throughput | 35.7Mpps@64Bytes |
| Address Table | 8K entries, automatic source address learning and ageing |
| Shared Data Buffer | 4 megabits |
| Flow Control | IEEE 802.3x pause frame for full duplex |
| Back pressure for half duplex | |
| Jumbo Frame | 9K bytes |
| Reset Button | < 5 sec: System reboot |
| > 5 sec: Factory Default | |
| LED | System: |
| Power (Green) | |
| WGSW-24040HP Alert: | |
| Fan 1 (Green), Fan 2 (Green), PWR (Green) | |
| WGSW-24040HP4 Alert: | |
| Fan 1 (Green), Fan 2 (Green), Fan 3 (Green), PWR (Green) | |
| PoE Ethernet Interfaces (Port 1 to Port 24): | |
| LNK/ACT (10/100/1000Mbps, Green), PoE-in-Use (Orange) | |
| 100/1000Mbps SFP Combo Interfaces (Port 21 to Port 24): | |
| 1000 (Green), 100 (None), LNK/ACT(Orange) | |
| Power Requirements | WGSW-24040HP: 100~240V AC, 50/60Hz, 4A |
| WGSW-24040HP4: 100~240V AC, 50/60Hz, 6A | |
| Power Consumption (Full Loading) | WGSW-24040HP: 262 watts |
| WGSW-24040HP4: 482 watts | |
| ESD Protection | 6KV DC |
| Dimensions (W x D x H) | 440 x 200 x 44.5 mm, 1U high |
| Weight | WGSW-24040HP: 4.25 kg |
| WGSW-24040HP4: 4.75 kg | |
| Layer 2 Management Function | |
| PoE Standard | IEEE 802.3at/802.3af Power over Ethernet |
| PoE Power Supply Type | End-span |
| PoE Power Output | Per port 52V DC, 590mA. max. 30.8 watts |
| Power Pin Assignment | 1/2(+), 3/6(-) |
| PoE Power Budget | WGSW-24040HP: 220 watts max. |
| WGSW-24040HP4: 440 watts max. | |
| PoE Ability | WGSW-24040HP: |
| 24 units: 24 units | |
| 14 units: 14 units | |
| 7 units: 7 units | |
| WGSW-24040HP4: | |
| 24 units: 24 units | |
| 14 units: 24 units | |
| 7 units: 14 units | |
| Layer 2 Management Function | |
| Basic Management Interfaces | Console; Telnet; Web Browser; SNMP v1, v2c |
| Secure Management Interfaces | SSH, SSL, SNMP v3 |
| Port Configuration | Port disable / enable |
| Auto-negotiation 10/100/1000Mbps full and half duplex mode selection | |
| Flow Control disable / enable | |
| Port Status | Display each port’s speed duplex mode, link status, flow control status, auto negotiation status, trunk status |
| Port Mirroring | TX / RX / Both |
| Many-to-1 monitor | |
| VLAN | 802.1Q tag-based VLAN, up to 255 VLAN groups |
| Q-in-Q tunneling | |
| Private VLAN Edge (PVE) | |
| MAC-based VLAN | |
| Protocol-based VLAN | |
| Voice VLAN | |
| MVR (Multicast VLAN Registration) | |
| Up to 255 VLAN groups, out of 4094 VLAN IDs | |
| Link Aggregation | IEEE 802.3ad LACP (static trunk) |
| Supports 12 trunks groups with 4 ports per trunk group | |
| QoS | Traffic classification based, strict priority and WRR |
| 8-Level priority for switching | |
| - Port Number | |
| - 802.1p priority | |
| - 802.1Q VLAN tag | |
| - DSCP/TOS field in IP packet | |
| IGMP Snooping | IGMP Snooping (v1/v2/v3), up to 255 multicast groups |
| IGMP Querier mode support | |
| MLD Snooping | MLD Snooping ((v1/v2), up to 255 multicast groups |
| MLD Querier mode support | |
| Access Control List | IP-based ACL / MAC-based ACL |
| Up to 256 entries | |
| Bandwidth Control | Per port bandwidth control |
| Ingress: 500Kb~80Mbps | |
| Egress: 64Kb~80Mbps | |
| SNMP MIBs | RFC 1213 MIB-II |
| IF-MIB | |
| RFC 1493 Bridge MIB | |
| RFC 1643 Ethernet MIB | |
| RFC 2863 Interface MIB | |
| RFC 2665 Ether-Like MIB | |
| RFC 2737 Entity MIB | |
| RFC 2819 RMON MIB (Groups 1, 2, 3 and 9) | |
| RFC 2618 RADIUS Client MIB | |
| RFC 3411 SNMP-Frameworks-MIB | |
| IEEE 802.1X PAE | |
| LLDP | |
| MAU-MIB | |
| Layer 3 Function | |
| IP Interface | Max. 8 VLAN interfaces |
| Routing Table | Max. 32 routing entries |
| Routing Protocols | IPv4 software static routing |
| IPv6 software static routing | |
| Standards Conformance | |
| Regulatory Compliance | FCC Part 15 Class A, CE |
| Standards Compliance | IEEE 802.3 10BASE-T |
| IEEE 802.3u 100BASE-TX/100BASE-FX | |
| IEEE 802.3z 1000BASE-SX/LX | |
| IEEE 802.3ab 1000BASE-T | |
| IEEE 802.3x flow control and back pressure | |
| IEEE 802.3ad port trunk with LACP | |
| IEEE 802.1D Spanning Tree protocol | |
| IEEE 802.1w Rapid Spanning Tree protocol | |
| IEEE 802.1s Multiple Spanning Tree protocol | |
| IEEE 802.1p Class of service | |
| IEEE 802.1Q VLAN tagging | |
| IEEE 802.1x Port Authentication Network Control | |
| IEEE 802.1ab LLDP | |
| IEEE 802.3af Power over Ethernet | |
| IEEE 802.3at Power over Ethernet PLUS | |
| RFC 768 UDP | |
| RFC 793 TFTP | |
| RFC 791 IP | |
| RFC 792 ICMP | |
| RFC 2068 HTTP | |
| RFC 1112 IGMP version 1 | |
| RFC 2236 IGMP version 2 | |
| RFC 3376 IGMP version 3 | |
| RFC 2710 MLD version 1 | |
| FRC 3810 MLD version 2 | |
| Environments | |
| Operating | Temperature: 0 ~ 50 degrees C |
| Relative Humidity: 5 ~ 95% (non-condensing) | |
| Storage | Temperature: -10 ~ 70 degrees C |
| Relative Humidity: 5 ~ 95% (non-condensing) | |
Planet WGSW 24040HP 10/100/1000 PoE Switch Pdf Dosyası1.52 MB
Teknik Kısa
PoE : PoE
Port Hızı : 1 GBit
Yönetilebilirlik : Yönetilebilir Layer 2 Plus
Aktarım Port Sayısı : 4
Aktarım Türü : Combo
PoE Port Sayısı :
24 Port
24 Port PoE Güç Bütçesi : 200-400 Watt
