ZyXEL XGS2210 28HP PoE Switch

Özellikler

Item	Features
Layer 3 Static Routing(Only for XGS2210)	IPv4/v6 Static Route
Layer 3 Static Routing(Only for XGS2210)	IPv4/v6 default Route
Standard Compliance	IEEE 802.3 10BASE-T Ethernet
	IEEE 802.3u 100BASE-TX Ethernet
	IEEE 802.3ab 1000BASE-T Ethernet
	IEEE 802.3z 1000BASE-X
	IEEE 802.3af PoE
	IEEE 802.3at PoE plus
	IEEE 802.3az EEE
	IEEE 802.3x ow control
	IEEE 802.3ad LACP aggregation
	IEEE 802.1AB LLDP/LLDP-MED
	IEEE 802.1D Spanning Tree Protocol (STP)
	IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
	IEEE 802.1s Multiple Spanning TreeProtocol (MSTP)
	IEEE 802.1Q VLAN tagging
	IEEE 802.1p Class of Service (CoS) prioritization
	IEEE 802.1X port authentication
Resilience and Availability	IEEE 802.1D Spanning Tree Protocol (STP)
	IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
	IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)
	IEEE 802.3ad LACP
	Loop guard
	Root guard
	BPDU guard
	ErrDisable recovery
	MRSTP (Zyxel Proprietary)
	Dual configuration les
	Dual images
	New Physical stacking (XGS2210 series only)
Traffic Control	802.1Q static VLANs/dynamic VLANs: 1 K/4 K
	Port-based VLAN
	Protocol-based VLAN
	IP subnet-based VLAN
	MAC-based VLAN
	Private VLAN
	Voice VLAN
	VLAN ingress filtering
	LACP algorithm of source/destination IP or MAC
	GVRP
	L2PT
	New for V4.50 VLAN mapping (XGS2210 series only)
Security	802.1X
	Port security
	Layer 2 MAC filtering
	Layer 3 IP filtering
	Layer 4 TCP/UDP socket filtering
	Static MAC forwarding
	Multiple RADIUS servers
	Multiple TACACS+ servers
	802.1x VLAN and 802.1p assignment by RADIUS
	Login authentication by RADIUS
	Login authentication by TACACS+
	TACACS+ accounting
	Authorization on RADIUS
	Authorization on TACACS+
	SSH v1/v2
	SSL
	Intrusion lock
	MAC freeze
	DHCP snooping
	ARP inspection
	Static IP-MAC-Port binding
	Policy-based security filtering
	Port isolation
	IP source guard (IPv4/IPv6)
	MAC search
	Guest VLAN
	ACL packet filtering (IPv4/IPv6)
	CPU protection
	Interface related trap enable/disable (by port)
	MAC-based authentication per VLAN
Quality of Service (QoS)	No. of hardware queues per port: 8
	Storm control: Broadcast, multicast, unknown unicast (DLF)
	Port-based rate limiting (ingress/egress)
	Rate limiting per IP/TCP/UDP per port
	Policy-based rate limiting
	802.3x ow control
	802.1p Class of Service (SPQ, WFQ, WRR, hybrid-SPQ combination capable)
	DiffServ (DSCP)
Layer 2 Multicast	L2 multicast
	IGMP snooping (v1, v2, v3)
	IGMP snooping fast leave
	Configurable IGMP snooping timer and priority
	IGMP snooping statistics
	IGMP throttling
	MVR support
	IGMP filtering
	IGMP snooping immediate leave
	IGMP proxy mode & snooping mode selection
	MLD snooping
	New for V4.50 IGMP leave proxy (GS2210 series only)
Routing (XGS2210 Series only)	Static route
	IP port moving
	New for V4.50 Assigned DHCP relay with specific source IP interface
Manageability	SNMP v1, v2c, v3
	SNMP trap group
	RMON (1, 2, 3, 9)
	ICMP echo/echo reply
	Syslog
	IEEE 802.1AB LLDP
	IEEE 802.1AB LLDP-MED
	New for V4.50 Custom default
	New for V4.50 Syslog (IPv4/IPv6)
	New for V4.50 Display port utilization
IPv6 Management	IPv6 over Ethernet (RFC 2464)
	IPv6 addressing architecture (RFC 4291)
	Dual stack (RFC 4213)
	ICMPv6 (RFC 4443)
	Path MTU (RFC 1981)
	Minimum path MTU size of 1280 (RFC 5095)
	Encapsulation for maximum PMTU of 1500
	Neighbor discovery (RFC 4861)
	DHCPv6 relay
	Default DHCP client mode
Device Management	Zyxel iStacking™
	Web interface
	Management through Console, Telnet, SNMP
	Remote firmware upgrade by FTP/Web/TFTP
	Configuration saving and retrieving
	Multiple logins supported
	Con gure clone
	Multilevel CLI
	CLI (Cisco-like)
	DHCP relay per VLAN
	DHCP client
	DHCP option 82
	New for V4.50 DHCP Auto (GS2210 series only)
	Daylight saving
	New for V4.50 NTP supports IPv4/ IPv6
	NTP
	Port mirroring
	RS-232 out-of-band console port
	Scheduled PoE
	New for V4.50 PoE default consumption mode
	sFlow (XGS2210 series only)
MIB	Zyxel new private MIB
	RFC 1066 TCP/IP-based MIB
	RFC 1213, 1157 SNMPv2c/v3 MIB
	RFC 1493 bridge MIB
	RFC 1643 Ethernet MIB
	RFC 1757 RMON group 1, 2, 3, 9
	RFC 2011, 2012, 2013 SNMPv2 MIB
	RFC 2233 SMIv2 MIB
	RFC 2358 Ethernet-like MIB
	RFC 2674 bridge MIB extension
	RFC 2819, 2925 remote management MIB
	RFC 3621 power Ethernet MIB
	RFC 4022 management information base for transmission control protocol
	RFC 4113 management information base for user datagram protocol
	RFC 4292 IP forwarding table MIB
	RFC 4293 Management Information Base (MIB) for IP
	New for V4.50 Cable diagnostic MIB
Certifications	Safety
	LVD
	BSMI
	EMC
	FCC Part 15 (Class A)
	CE EMC (Class A)
	BSMI EMC
	RoHS
	Level A
Zyxel One Network	ZON Utility
	Discovery of Zyxel switches, APs and gateways
	Centralized and batch configurations
	IP configuration
	IP renew
	Device factory reset
	Device reboot
	Device locating
	Web GUI access
	Password configuration
	One-click quick association with Zyxel AP Configurator (ZAC)
	Smart Connect
	Discover neighboring devices
	One-click remote management access to the neighboring Zyxel devices
	Reset neighboring devices remotely to factory defaults
	Power cycle neighboring powered devices (PoE switches only)
Warranty	Limited life-time warranty
Warranty	*Warranty terms, service availability, and service response times may vary from country or region to country or region.
