Cisco Catalyst 2960 24PC L PoE Switch

Power Rating	0.470 kVA
Dimensions (H x W x D)	1.73 x 17.5 x 12.9 in. (4.4 x 44.5 x 32.8 cm.)
Max. Watt Power Consumption	470W (dissipated power 100W)
DC input voltages (RPS input)	12 V at 11.25 A (-48 V at 7.8 A)
Operating Relative Humidity	10% to 95% noncondensing
Unicast MAC Addresses	8000
Operating Temperature up to 5000 ft (1500 m)	23 to 113 F (-5 to 45 C)
Available PoE Power	370W (24 ports up to 15.4W)
Short-term Exception up to 10,000 feet (3000 m)	23 to 113 F (-5 to 45 C)
MTBF	311,781 hours
IPv4 IGMP Groups	255
Operating Temperature up to 10,000 ft (3000 m)	23 to 104 F (-5 to 40 C)
Maximum Transmission Unit (MTU)	Up to 9000 bytes
Short-term Exception up to 5000 feet (1500 m)	23 to 122 F (-5 to 50 C)
Voltage	100 to 240 VAC (Autoranging); 50 to 60 Hz
Short-term Exception at Sea Level	23 to 131 F (-5 to 55 C)
Operating Altitude	Up to 10,000 feet (3000 m)
Packets per second (Mpps)	6.May
Max VLANs	255
Rack Height	1 RU
AC/DC Support	AC only
Ports	24 Ethernet 10/100 ports
Switching Bandwidth	32 Gbps
Uplinks	2 dual-purpose ports (10/100/1000 or SFP)
Weight	12 lbs (5.4 kg)
Short-term Exception up to 13,000 feet (4000 m)	23 to 104 F (-5 to 40 C)
Storage Altitude	Up to 13,000 feet (4000 m)
Memory DRAM	64 MB
Storage Relative Humidity	10% to 95% noncondensing
Model	LAN Base Layer 2
Forwarding Bandwidth	16 Gbps
Flash Memory	32 MB
Storage Temperature up to 15,000 feet (4573 m)	-13 to 158 F (-25 to 70 C)
VLAN IDs	4000
Jumbo Frames	9018 bytes
