Huawei S5720 28X PWR SI AC 10/100/1000 PoE Switch
Teknik Özellikler
| Fixed Ports |
| 24 Ethernet 10/100/1,000 ports, 4 of which are dual-purpose 10/100/1,000 or SFP |
| 4 x 10 Gig SFP+ |
| Extended Slot |
| N/A |
| MAC Address Table |
| IEEE 802.1d compliance |
| 16K MAC address entries |
| MAC address learning and aging |
| Static, dynamic, and black hole MAC address entries |
| Packet filtering based on source MAC addresses |
| VLAN |
| 4K VLANs |
| Guest VLAN and voice VLAN |
| GVRP |
| MUX VLAN |
| VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports |
| 1:1 and N:1 VLAN Mapping |
| Ring Protection |
| RRPP ring topology and RRPP multi-instance |
| Smart Link tree topology and Smart Link multi-instance, providing the millisecond-level protection switchover |
| SEP |
| ERPS (G.8032) |
| STP (IEEE 802.1d), RSTP (IEEE 802.1w), and MSTP (IEEE 802.1s) |
| BPDU protection, root protection, and loop protection |
| IP Routing |
| Static route, RIPv1, RIPv2, RIPng, ECMP, OSPF, OSPFv3, BGP, BGP4+, IS-IS, IS-ISv6, VRRP, and VRRP6 |
| IPv6 Features |
| Neighbor Discovery (ND) |
| Path MTU (PMTU) |
| IPv6 ping, IPv6 tracert, and IPv6 Telnet |
| ACLs based on the source IPv6 address, destination IPv6 address, Layer 4 ports, or protocol type |
| MLD v1/v2 snooping |
| 6to4 tunnel, ISATAP tunnel, and manually configured tunnel |
| Multicast |
| PIM DM, PIM SM, PIM SSM |
| IGMP v1/v2/v3 snooping and IGMP fast leave |
| Multicast forwarding in a VLAN and multicast replication between VLANs |
| Multicast load balancing among member ports of a trunk |
| Controllable multicast |
| Port-based multicast traffic statistics |
| QoS/ACL |
| Rate limiting on packets sent and received by an interface |
| Packet redirection |
| Port-based traffic policing and two-rate three-color CAR |
| Eight queues on each port |
| WRR, DRR, SP, WRR + SP, and DRR + SP queue scheduling algorithms |
| Re-marking of the 802.1p priority and DSCP priority |
| Packet filtering at Layer 2 to Layer 4, filtering out invalid frames based on the source |
| MAC address, destination MAC address, source IP address, destination IP address |
| TCP/UDP port number, protocol type, and VLAN ID |
| Rate limiting in each queue and traffic shaping on ports |
| Security |
| User privilege management and password protection |
| DoS attack defense, ARP attack defense, and ICMP attack defense |
| Binding of the IP address, MAC address, interface, and VLAN |
| Port isolation, port security, and sticky MAC |
| Blackhole MAC address entries |
| MAC Forced Forwarding (MFF) |
| Limit on the number of learned MAC addresses |
| 802.1x authentication and limit on the number of users on an interface |
| AAA authentication, RADIUS authentication, HWTACACS+ authentication, and NAC |
| SSH v2.0 |
| Hypertext Transfer Protocol Secure (HTTPS) |
| CPU defense |
| Blacklist and whitelist |
| 802.1x authentication, MAC address authentication, and combined authentication on a per port basis |
| Portal authentication on a per VLANIF interface basis |
| MACSec |
| Super Virtual Fabric (SVF) |
| Working as an SVF client that is plug-and-play with zero configuration |
| Automatically loading the system software package and patches of clients |
| One-click and automatic delivery of service configurations |
| Supports independent running client |
| Management and Maintenance |
| iStack |
| Virtual cable test |
| SNMP v1/v2c/v3 |
| RMON |
| Web-based NMS |
| System logs and alarms of different levels |
| sFlow |
| Interoperability |
| Supports VBST (Compatible with PVST/PVST+/RPVST) |
| Supports LNP (Similar to DTP) |
| Supports VCMP (Similar to VTP) |
| Surge Protection |
| Surge protection capability of service ports: 6 kV |
| Operating Environment |
| Operating temperature: |
| Zero to 1,800m altitude: 0°C to 45°C |
| 1,800m to 5,000m altitude: Operating temperature reduces by 1°C for every 220m increase in altitude |
| Relative humidity: 5% to 95% (non-condensing) |
| Input Voltage |
| AC: |
| Rated voltage range: 100V to 240V, 50 Hz/60 Hz |
| Maximum voltage range: 90V to 264V, 50 Hz/60 Hz |
| DC: |
| Rated voltage range: –48V to –60V |
| Maximum voltage range: –36V to –72V |
| Dimensions (W x D x H) |
| 442 mm x 420 mm x 44.4 mm |
| Typical Power Consumption |
| Without PD: 31.8W; with PD: < 913W (PoE: 740W) |
Huawei S5720 28X PWR SI AC 10/100/1000 PoE Switch Pdf Dosyası843.54 KB
Teknik Kısa
PoE : PoE
Port Hızı : 1 GBit
Yönetilebilirlik : Yönetilebilir
Aktarım Port Sayısı : 4
Aktarım Türü : Combo
PoE Port Sayısı :
24 Port
24 Port PoE Güç Bütçesi : 400-800 Watt
