Planet GS-6320-24UP2T2XV PoE Switch

Özellikler

Physical Port
  • 24 10/100/1000BASE-T Gigabit RJ45 copper ports with 24-port IEEE 802.3bt PoE++ injector function
  • 2 10GBASE-T RJ45 interfaces with auto MDI/MDI-X function
  • 2 10GBASE-SR/LR SFP+ slots, compatible with 1000BASE-SX/LX/BX SFP
  • RJ45 console interface for switch basic management and setup
  • Complies with IEEE 802.3bt Power over Ethernet Plus Plus
  • Backward compatible with IEEE 802.3af /at Power over Ethernet
  • Up to 24 ports of IEEE 802.3af/IEEE 802.3at/IEEE 802.3bt PoE devices powered
  • 8 PoE ports with built-in 802.3bt PoE++ Type-4 90W injector function (Port-1 to Port-8)
  • 16 PoE ports with built-in 802.3bt PoE++ Type-3 60W injector function (Port-9 to Port-24)
  • Auto detects powered device (PD)
  • Circuit protection prevents power interference between ports
  • Remote power feeding up to 100 meters
  • PoE management
    - Total PoE power budget control
    - Per port PoE function enable/disable
    - PoE admin-mode control
    - PoE port power feeding priority
    - Per PoE port power limitation
    - PD classification detection
    - Temperature threshold control
    - PD alive check
    - PoE schedule
Layer 2 Features
  • Prevents packet loss with back pressure (half-duplex) and IEEE 802.3x pause frame flow control (full-duplex)
  • High performance of Store-and-Forward architecture and runt/CRC filtering eliminates erroneous packets to optimize the network bandwidth
  • Storm Control support
    - Broadcast/Multicast/Unknown unicast
  • Supports VLAN
    - IEEE 802.1Q tagged VLAN
    - Up to 255 VLANs groups, out of 4094 VLAN IDs
    - Supports provider bridging (VLAN Q-in-Q, IEEE 802.1ad)
    - Private VLAN Edge (PVE)
    - Protocol-based VLAN
    - MAC-based VLAN
    - Voice VLAN
    - GVRP (GARP VLAN Registration Protocol)
  • Supports Spanning Tree Protocol
    - IEEE 802.1D Spanning Tree Protocol (STP)
    - IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
    - IEEE 802.1s Multiple Spanning Tree Protocol (MSTP), spanning tree by VLAN
    -BPDU Guard
  • Supports Link Aggregation
    - 802.3ad Link Aggregation Control Protocol (LACP)
    - Cisco ether-channel (static trunk)
    - Maximum 26 trunk groups with 4 ports for each trunk group
    - Up to 80Gbps bandwidth (full duplex mode)
  • Provides port mirror (many-to-1)
  • Port mirroring to monitor the incoming or outgoing traffic on a particular port
  • Loop protection to avoid broadcast loops
  • Supports ERPS (Ethernet Ring Protection Switching)
  • Compatible with Cisco uni-directional link detection(UDLD) that monitors a link between two switches and blocks the ports on both ends of the link if the link fails at any point between the two devices
  • Link Layer Discovery Protocol (LLDP)
Layer 3 Features
  • IP dynamic routing protocol supports OSPFv2
  • IPv4/IPv6 hardware static routing
  • Routing interface provides per VLAN routing mode
  • IP interfaces (Max. 128 VLAN interfaces)
  • Routing table (Max. 128 routing entries)
Quality of Service
  • Ingress Shaper and Egress Rate Limit per port bandwidth control
  • 8 priority queues on all switch ports
  • Traffic classification
    - IEEE 802.1p CoS
    - TOS/DSCP/IP precedence of IPv4/IPv6 packets
    - IP TCP/UDP port number
    - Typical network application
  • Strict priority and Weighted Round Robin (WRR) CoS policies
  • Supports QoS and In/Out bandwidth control on each port
  • Traffic-policing on the switch port
  • DSCP remarking
Multicast
  • Supports IPv4 IGMP snooping v1, v2 and v3
  • Supports IPv6 MLD snooping v1 and v2
  • Querier mode support
  • IPv4 IGMP snooping port filtering
  • IPv6 MLD snooping port filtering
  • Multicast VLAN Registration (MVR) support
Security
  • Authentication
    - IEEE 802.1x port-based/MAC-based network access authentication
    - Built-in RADIUS client to cooperate with the RADIUS servers
    - TACACS+ login users access authentication
    - RADIUS/TACACS+ users access authentication
  • Access Control List
    - IP-based Access Control List (ACL)
    - MAC-based Access Control List
  • Source MAC/IP address binding
  • DHCP Snooping to filter untrusted DHCP messages
  • Dynamic ARP Inspection discards ARP packets with invalid MAC address to IP address binding
  • IP Source Guard prevents IP spoofing attacks
  • IP address access management to prevent unauthorized intruder
Management
  • IPv4 and IPv6 dual stack management
  • Switch Management Interfaces
    - Console/Telnet Command Line Interface
    - Web switch management
    - SNMP v1, v2c, and v3 switch management
    - SSH, TLS, SSL and SNMP v3 secure access
  • SNMP Management
    - Four RMON groups (history, statistics, alarms and events)
    - SNMP trap for interface Link Up and Link Down notification
  • IPv6 IP address/NTP/DNS management
  • Built-in Trivial File Transfer Protocol (TFTP) client
  • BOOTP and DHCP for IP address assignment
  • System Maintenance
    - Firmware upload/download via HTTP/TFTP
    - Reset button for system reboot or reset to factory default
    - Dual images
  • DHCP Relay and DHCP Option 82
  • DHCP Server
  • User Privilege levels control
  • NTP (Network Time Protocol)
  • Network Diagnostic
    - ICMPv6/ICMPv4 remote ping
    - Cable diagnostic technology provides the mechanism to detect and report potential cabling issues
  • SMTP/Syslog remote alarm
  • System Log
  • PLANET Smart Discovery Utility for deployment management
  • Smart fan with speed control
Redundant Power System
  • Redundant 100~240V AC/36-60V DC dual power
  • Active-active redundant power failure protection
  • Backup of catastrophic power failure on one supply
  • Fault tolerance and resilience

pdfPlanet GS-6320-24UP2T2XV PoE Switch Pdf Dosyası2.92 MB

pdfPlanet GS-6320-24UP2T2XV PoE Switch Kullanım Kılavuzu (ing) Pdf Dosyası21.76 MB

Teknik Kısa

PoE : PoE
Port Hızı : 1 GBit
Yönetilebilirlik : Yönetilebilir
Aktarım Port Sayısı : 4
Aktarım Türü : Rj45
Gbit Fiber
PoE Port Sayısı : Tooltip 24 Port
PoE Güç Bütçesi : 400-800 Watt
