| Rack-Mount 23 in. (58.4 cm) EIA |
Included |
| Jumbo Frame Support |
10 KB |
| Routing Protocol |
Static IPv4 routing |
| Minimum Storage Temperature |
-4 F |
| Depth |
13.8 inches |
| MTBF |
182,540 hour(s) |
| Cables Included |
1x Serial Cable |
| Capacity |
4K Active VLANs |
| Height |
1.5 inches |
| Maximum Operating Temperature |
104 F |
| MAC Address Table Size |
16k entries |
| Localization |
Chinese (simplified), English, German, French, Italian, Spanish, Japanese |
| Width |
17.3 inches |
| Enclosure Type |
Desktop, rack-mountable - 1U |
| Maxiumum Storage Temperature |
158 F |
| Ports |
48 x 10/100 + 2 x combo Gigabit SFP + 2 x 10/100/1000 |
| Device Type |
Switch - 48 ports - L3 - managed |
| Humidity Operating Range |
10-90% (non-condensing) |
| Weight |
13 lbs |
| Minimum Operating Temperature |
32 F |
| Interfaces |
48 x 10Base-T/100Base-TX - RJ-45 - PoE; 1 x console - 9 pin D-Sub (DB-9) - management; 4 x 10Base-T/100Base-TX/1000Base-T - RJ-45; 2 x SFP (mini-GBIC) |
| Humidity Storage Range |
10-90% (non-condensing) |
| Flash Memory |
16 MB |
| Voltage Required |
AC 120/230 V ( 50/60 Hz ) |
| Performance |
Switching capacity 17.6 Gbps; Forwarding performance (64-byte packet size) 13.1 Mpps |
| Power Device |
Power adapter - external |
| Power Over Ethernet (PoE) |
PoE |
| Status Indicators |
Link activity, port transmission speed, system |
| Ram |
128 MB |
| Authentication Method |
Secure Shell (SSH), RADIUS, TACACS+ |
