HP 1910 8 PoE Plus JG537A PoE Switch
Teknik Özellikler
Networking |
Advanced Switching: Layer 3 |
Compliant Standards: IEEE 802.1ab (LLDP) , IEEE 802.1D , IEEE 802.1p , IEEE 802.1Q , IEEE 802.1s , IEEE 802.1w , IEEE 802.1x , IEEE 802.3 , IEEE 802.3ab , IEEE 802.3ad (LACP) , IEEE 802.3i , IEEE 802.3u , IEEE 802.3x , IEEE 802.3z |
Features: Access Control List (ACL) support , ARP support , Auto-negotiation , Auto-uplink (auto MDI/MDI-X) , Cable Diagnostics Function , DHCP relay , DHCP support , DoS attack prevention , Dual firmware images , Flow control , Full duplex mode , Half duplex mode , IGMP snooping , IPv4 support , IPv6 support , Jumbo Frames support , Layer 2 switching , Layer 3 switching , Link Aggregation Control Protocol (LACP) , Link aggregation trunking , LLDP support , MLD snooping , Multiple Spanning Tree Protocol (MSTP) support , NTP time synchronization , Packet storm protection , Port mirroring , Quality of Service (QoS) , Rapid Spanning Tree Protocol (RSTP) support , Spanning Tree Protocol (STP) support , STP Root Guard , VLAN support |
Form Factor: Rack-mountable |
Manageable: Yes |
Ports Qty: 8 |
Power Over Ethernet (PoE): PoE+ |
Remote Management Protocol: HTTP , HTTPS , RMON 2 , SNMP , SNMP 1 , SNMP 2c , SNMP 3 |
Routing Protocol: Static IPv4 routing , Static IPv6 routing |
Subcategory: Network hubs and switches |
Subtype: Fast Ethernet |
Type: Switch |
Capacity |
Type: Routing table entries |
Value: 32 |
Dimensions & Weight |
Weight: 4.63 lbs |
Header |
Brand: HPE |
Compatibility: PC |
Country Kits: United States |
Localization: English |
Manufacturer: ProCurve Networking |
Model: 1910-8-PoE+ Switch |
Packaged Quantity: 1 |
Product Line: HPE |
Interface Provided |
Comments: PoE |
Connector Type: RJ-45 |
Qty: 8 |
Type: 100Base-TX |
Connector Type: SFP |
Qty: 2 |
Type: 1000Base-X |
Type: 1000Base-T |
Miscellaneous |
Authentication Method: RADIUS |
Compliant Standards: CISPR 22 Class A , CSA C22.2 No. 60950-1-03 , EN 60950-1 , EN 61000-3-2 , EN 61000-3-3 , EN55022 Class A , EN55024 , FCC Class A certified , FCC Part 15 , ICES-003 Class A , IEC 60950-1 , UL 60950 , VCCI Class A ITE |
Encryption Algorithm: SSL |
Height (Rack Units): 1 |
Rack Mounting Kit: Included |
Ports |
Qty: 8 |
Type: 10/100 (PoE+) |
Ports (2nd) |
Qty: 2 |
Type: Combo Gigabit SFP |
Power Device |
Frequency Required: 50/60 Hz |
Nominal Voltage: AC 120/230 V |
Service |
Support Details Full Contract Period: Lifetime |
Support Details Type: Limited warranty |
Service & Support |
Type: Limited lifetime warranty |
Teknik Kısa
PoE : PoE Plus
Port Hızı : 100 Mbps
Yönetilebilirlik : Yönetilebilir Layer 3
Aktarım Port Sayısı : 2
Aktarım Türü : Combo
PoE Port Sayısı : 8 Port
PoE Güç Bütçesi : 50-130 Watt
