| Image Sensor: 1/3" CMOS |
| Effective Pixels: 1280(H) x 960(V) |
| Scanning System: Progressive |
| Electronic Shutter Speed: 1/3(4)~1/10000s |
| Min. Illumination: Color: 0.05Lux/F1.6 B/W: 0.005Lux/F1.6 |
| S/N Ratio: More than 50dB |
| Video Output: BNC(1.0Vp-p/75Ω), PAL / NTSC |
| Day/Night: Auto(ICR) / Color / B/W |
| Backlight Compensation: BLC / HLC / WDR |
| White Balance: Auto, ATW, Indoor, Outdoor, Manual |
| Gain Control: Auto / Manual |
| Noise Reduction: 2D / 3D |
| Privacy Masking: Up to 24 areas |
| Digital Zoom: 16x |
| Focal Length: 4.7mm~84.6mm(18x Optical zoom) |
| Max Aperture: F1.6~F2.7 |
| Focus Control: Auto / Manual |
| Angle of View: H: 55.2°~3.2° |
| Close Focus Distance: 100mm(wide) ~ 1500mm(Tele) |
| Pan/Tilt Range: Pan: 0° ~ 360° endless; Tilt: -2° ~ 90°, auto flip 180° |
| Manual Control Speed: Pan: 0.1° ~ 300°/s; Tilt: 0.1° ~ 250°/s |
| Preset Speed: Pan: 400°/s; Tilt: 300°/s |
| Preset: 80(DH-SD), 255(Pelco-P/D) |
| PTZ Mode: 5 Pattern, 8 Tour, Auto Pan, Auto Scan |
| Speed Setup: Human-oriented focal length/ speed adaptation |
| Power up Action: Auto restore to previous PTZ and lens status after power failure |
| Idle Motion: Activate Preset/Pan/Scan/Tour/Pattern if there is no command in the specified period |
| Time Task: Auto activation of Preset/Pan/Scan/Tour/Pattern by preset-time |
| Protocol: DH-SD, Pelco-P/D (Auto recognition) |
| Compression: H.264 / MJPEG |
| Resolution: 1.3M(1280×960)/720P(1280×720)/D1(704×576/704×480)/CIF(352×288/352×240) |
| Bit Rate: H.264: 56K ~ 8192Kbps, MJPEG: 56K ~ 20480Kbps |
| Compression: G.711a / G.711u(32kbps) / PCM(128kbps) |
| Interface: 1/1 channel In/Out |
| Ethernet: RJ-45 (10/100Base-T) |
| Max. User Access: 20 users |
| Smart Phone: iPhone, iPad, Android, Windows Phone |
| Memory Slot: Micro SD, Max 64GB |
| RS485: 1 |
| Alarm: 7/2 channel In/Out |
| Power Supply: AC 24V/3A (±10%) /DC12V optional (Outdoor),AC 24V/2.2A (±10%) (Indoor in-ceiling) |
| Power Consumption: 15W, 40W(Heater on) |
| Working Environment: -40ºC ~ 60ºC / Less than 90% RH |
| Ingress Protection: IP67 (Outdoor) |
| Vandal Resistance: IK10 (optional) |
| Dimensions: Φ222(mm) x 322(mm) (Outdoor),Φ211(mm) x 224.6(mm) (Indoor in-ceiling) |
| Weight: 5.0kg |
