| Kamera |
| Görüntü Sensörü |
1/3” CMOS |
| Effective Pixels |
2048(H) x 1536(V), 3 Megapixels |
| Scanning System |
Progressive |
| Electronic Shutter Hızı |
1/1 ~ 1/30,000s |
| Min.Aydınlatma |
Color: 0.05Lux @ F1.6, B/W: 0.005Lux @ F1.6 |
| S/N Oranı |
More than 50dB |
| Video Çıkış |
BNC(1.0Vp-p/75Ω), PAL / NTSC |
| Kamera Özellikleri |
| Max.IR Mesafesi |
100mt |
| Day/Night |
Auto(ICR) / Color / B/W |
| Arka Işık Telafisi |
BLC / HLC / WDR (100db, 1080P mode) |
| Beyaz Denge |
Auto, ATW, Indoor, Outdoor, Manual |
| Kazanç Kontrolü |
Auto / Manual |
| Gürültü Azaltma |
2D / 3D |
| Gizlilik Maskesi |
Up to 24 areas |
| Digital Zoom |
16x |
| Lens |
| Focal Length |
4.7mm ~ 94.0mm(20x Optical zoom) |
| Max Aperture |
F1.6 ~ F3.5 |
| Focus Control |
Auto / Manual |
| Angle of View |
H: 58.2° ~ 2.9° |
| Close Focus Distance |
10mm ~ 1000mm |
| PTZ |
| Pan/Tilt Range |
Pan: 0° ~ 360° endless; Tilt: -2° ~ 90°, auto flip 180° |
| Manual Control Speed |
Pan: 0.1° ~ 160°/s; Tilt: 0.1° ~120°/s |
| Preset Speed |
Pan: 240°/s; Tilt: 200°/s |
| Preset |
80(DH-SD), 255(Pelco-P/D) |
| PTZ Mode |
5 Pattern, 8 Tour, Auto Pan, Auto Scan |
| Speed Setup |
Human-oriented focal length/ speed adaptation |
| Power up Action |
Auto restore to previous PTZ and lens status after power failure |
| Idle Motion |
Activate Preset/Pan/Scan/Tour/Pattern if there is no command in the specified period |
| Time Task |
Auto activation of Preset/Pan/Scan/Tour/Pattern by preset-time |
| Protocol |
DH-SD, Pelco-P/D (Auto recognition) |
| Video |
| Sıkıştırma |
H.264 / MJPEG |
| Çözünürlük |
3MP(2048×1536) / 1080P(1920×1080) / 720P(1280×720) / D1(704×576/704×480) / CIF(352×288/352×240) |
| Frame Hızı |
Main Stream |
3MP(1 ~ 15fps) / 1080P/720P(1 ~ 25/30fps) |
| Sub Stream |
D1/CIF(1 ~ 25/30fps) |
| Bit Hızı |
H.264: 56K ~ 8192Kbps, MJPEG: 56K ~ 20480Kbps |
| Ses |
| Sıkıştırma |
G.711a / G.711u (32kbps) / PCM (128kbps) |
| Arayüz |
1/1 channel In/Out |
| Network |
| Ethernet |
RJ-45 (10/100Base-T) |
| Protocol |
IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour |
