| CAMERA |
| Detector Type | Long-Life,Uncooled IRFPA Microbolometer |
| Effective Resolution | 396x264 |
| Pixel Pitch | 20μm |
| Sensitivity | 50mK |
| Spectral Range | 8 to 14μm |
| Temperature Response | 30ms |
| Thermal Motorized Lens | 100 mm |
| Vision Lens | Optional 10-320mm (C/CS Mount) |
| Focus | Motorized |
| FOV(Motorized Lens) | 3.6°×2.7° |
| Temperature Detect Distance(Fire) | 2600m |
| Motorized Lens Recognition Distance (Body) | 1000m |
| Motorized Lens Recognition Distance (Vehicle) | 2000m |
| IMAGE |
| Video Compression | H.264 High/Main/Baseline Profile, MJPEG |
| Bit Rate (CBR/VBR) | 500Kb-10Mb |
| Audio Compression | G.711 ,RAW_PCM,NONE |
| Thermal Resolution | D1/30fps |
| Stream | D1/CIF |
| Image Color Mode | Black-Heat /White-Heat/Rainbow/Iron-Red up to 17 modes |
| DVE Image Enhance | Yes |
| 3D Noise Reduce | Yes |
| Image Correction | Auto/Manual/External |
| Image Overturn | Horizontal /Vertical /Horizontal+Vertical |
| NETWORK |
| Network Protocols | IPv4/v6,RTSP/RTP/RTCP,TCP/UDP,HTTP,DHCP,DNS,FTP,DDNS,PPPOE,SMTP,SIP |
| Alarm Trigger | Temperature Alarm,MotionDetection,Networkdisconnect,Diskalarm,I/O alarm |
| RTSP Video | Standard RFC2326, Support QuickTime / VLC Player. |
| Security | User security authentication, Reset, Hardware WatchDog |
| Web Language | English, Chinese |
| System Compatibility | Onvif |
| Interface |
| Ethernet | 1 Ethernet (10/100 Base-T) RJ-45 Connector |
| Audio I/O | Optional |
| Alarm I/O | Optional |
| RS485 | Yes |
| BNC Output | Yes |
| Reset Button | Yes(built-in) |
| Edge Storage | Micro SD/SDHC slot ,Max 32GB |
| GENERAL |
| Power Supply | AC24V±20%,50/60HZ |
| Power Consumption | 100W(MAX) |
| OperatingTemperature | -25℃~+55℃ |
| Ingress Protection | IP66 |
| Approvals | CE / FCC |
| Product Dimensions | 760×335×573mm |
| Product Weight | 50Kg |
